Chevrolet Silverado GMT K2XX facelift (2015-2019) wiper sw hi sig Wiring diagram
This page shows the only wiring diagram for the component.wiper sw hi sig, which is found in the car Chevrolet Silverado GMT K2XX facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper sw hi sig (1 of 1)
BATT POS VOLT
BCM 1 FUSE
BCM 2 FUSE
BLK WIRE
BLK/GRY WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BRN/GRY WIRE
BRN/LT GRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DRIVER INFORMATION CENTER DISPLAY
FRT WASH FUSE
FRT WPR FUSE
GRY WIRE
GRY/GRN WIRE
GRY/VIO WIRE
HI LO
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL JUNCTION BLOCK
J124 (EXCEPT 6.6L) J123 (6.6L)
LEFT INSTRUMENT PANEL FUSE BLOCK
LO WASHER FLUID IND CTRL
LOGIC
LOW REF
MIST
MIST HI OFF LO INT INT
MTR PARK SW SIG
OFF
RED WIRE
RED/BRN WIRE
RED/WHT WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
SERIAL DATA (-) (1)
SERIAL DATA 2
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
VIO WIRE
W/ BASE EQUIPMENT
W/O BASE EQUIPMENT
WASHER RLY CTRL
WASHER SW SIG
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/VIO WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER PUMP
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER MTR RLY COIL SUPPLY VOLT
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SPEED CONTROL RELAY
WINDSHIELD WIPER SW HI SIG
WIPER SW HI SIG
WIPER SW LOW SIG
WIPER SWITCH
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> Wiper/washer circuit -> WIPER SW HI SIG
