Chevrolet Silverado GMT K2XX facelift (2015-2019) w/ color light sensitive w/o color light sensitive Wiring diagram
This page shows the only wiring diagram for the component.w/ color light sensitive w/o color light sensitive, which is found in the car Chevrolet Silverado GMT K2XX facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ color light sensitive w/o color light sensitive (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN/GRN WIRE
BRN/WHT WIRE
DRIVER OUTSIDE REAR VIEW MIRROR CARGO LAMP
DRIVER OUTSIDE REAR VIEW MIRROR COURTESY LAMP
DRIVER OUTSIDE REAR- VIEW MIRROR
GRN/VIO WIRE
GRY/BRN WIRE
GRY/GRN WIRE
LEFT CARGO LAMP
LEFT MIDDLE SIDE MARKER LAMP
LEFT TURN SIGNAL REPEATER LAMP
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR CARGO LAMP
PASSENGER OUTSIDE REAR VIEW MIRROR COURTESY LAMP
RED WIRE
RED/GRN WIRE
RIGHT CARGO LAMP
RIGHT MIDDLE SIDE MARKER LAMP
RIGHT TURN SIGNAL REPEATER LAMP
VIO/GRY WIRE
VIO/WHT WIRE
W/ COLOR LIGHT SENSITIVE W/O COLOR LIGHT SENSITIVE
WHT/VIO WIRE
YEL/BLU WIRE
Go to component -> Exterior lamps circuit (5 of 7) -> W/ COLOR LIGHT SENSITIVE W/O COLOR LIGHT SENSITIVE
