Chevrolet Silverado GMT K2XX facelift (2015-2019) voice low ref Wiring diagram
This page shows the only wiring diagram for the component.voice low ref, which is found in the car Chevrolet Silverado GMT K2XX facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram voice low ref (1 of 1)
AUDIO SIG +
BLK WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/LT GRN WIRE
COMPUTER DATA LINES SYSTEM
DIM SWITCH SIG
DISPLAY SIGNAL (-)
DOWN SIGNAL
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/YEL WIRE
INFO DISPLAY MODULE
KEYPAD CONTROL
LCD DIMMING SIGNAL
LEFT FRONT DOOR SPEAKER
LEFT INSTRUMENT PANEL SPEAKER
LEFT REAR DOOR SPEAKER
LEFT REAR TRIM PANEL SPEAKER
LOW REF
LVDS
MICROPHONE SIG
RADIO CONTROLS
RADIO ON SIGNAL
REGULATED CONTROL
REQUEST SIGNAL
RESET SIGNAL
RIGHT FRONT DOOR SPEAKER
RIGHT INSTRUMENT PANEL SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT REAR TRIM PANEL DOOR SPEAKER
SER DATA (+) 9
SWITCH DIM SIGNAL
SWITCH SIGNAL 2
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
UP SIGNAL
VIO/GRY WIRE
VOICE LOW REF
VOICE SIGNAL
W/ ENHANCED AUDIO SPEAKER SYSTEM
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Radio circuit, mid level (3 of 3) -> VOICE LOW REF
