Chevrolet Silverado GMT K2XX facelift (2015-2019) transmission range switch sig a Wiring diagram
This page shows the only wiring diagram for the component.transmission range switch sig a, which is found in the car Chevrolet Silverado GMT K2XX facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission range switch sig a (1 of 1)
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DK BLU WIRE
FROM AUTOMATIC TRANSMISSION ASSEMBLY (DIAGRAM 1 OF 2)
FTP SWITCH 1 VOLTAGE
FTP SWITCH 3 VOLTAGE
FTP SWITCH 4 VOLTAGE
FTP SWITCH 5 VOLTAGE
GMLAN SERIAL DATA - 1
GRN WIRE
GRY WIRE
INPUT SPEED SENSOR SIG
ISS/OSS SUPPLY VOLTAGE
NCA WIRE
OUTPUT SPEED SENSOR SIG
RED WIRE
SHIFT
TAP UP/ TAP DOWN SW SIG
TOW/ HAUL MODE SWITCH
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID PRESSURE SWITCH
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SHAFT SPEED SENSOR
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
TRANSMISSION RANGE SWITCH SIG A
TRANSMISSION RANGE SWITCH SIG B
TRANSMISSION RANGE SWITCH SIG C
TRANSMISSION RANGE SWITCH SIG P
TRANSMISSION SHIFT LEVER
VIO/YEL WIRE
WHT WIRE
YEL WIRE
Go to component -> A/t circuit, 6 speed (2 of 2) -> TRANSMISSION RANGE SWITCH SIG A
