Chevrolet Silverado GMT K2XX facelift (2015-2019) sw close sig Wiring diagram
This page shows the only wiring diagram for the component.sw close sig, which is found in the car Chevrolet Silverado GMT K2XX facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sw close sig (1 of 1)
ACC VOLT
BATT POS SIG
BLK WIRE
BLU/WHT WIRE
BRN/BLU WIRE
CLOSE OPEN
EXPRESS CLOSE
EXPRESS OPEN
GRN/WHT WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RETAINED ACCESSORY POWER RELAY 1 ENERGIZED
ILL
LEFT INSTRUMENT PANEL FUSE BLOCK
LOGIC SUNROOF MOTOR
OPEN CLOSE
RED/LT GRN WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
SEO RAP FUSE
SUNROOF FUSE
SUNROOF SWITCH
SW CLOSE SIG
SW CLOSE VENT SIG
SW EXPRESS SIG
SW OPEN SIG
SW OPEN VENT SIG
VIO/YEL WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Power top/sunroof circuit -> SW CLOSE SIG
