Chevrolet Silverado GMT K2XX facelift (2015-2019) lo coolant level ind ctrl Wiring diagram
This page shows the only wiring diagram for the component.lo coolant level ind ctrl, which is found in the car Chevrolet Silverado GMT K2XX facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lo coolant level ind ctrl (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/VIO WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
COOL FAN CLTCH FUSE
COOLING FAN CONTROL MODULE
COOLING FAN RELAY
CTRL SIG
DATA 1 (+)
DK BLU WIRE
DRIVER INFORMATION CENTER DISPLAY
ECT SENS SIG
ENGINE CONTROL MODULE
ENGINE COOLANT LEVEL SWITCH
ENGINE COOLANT TEMPERATURE GAUGE
ENGINE COOLANT TEMPERATURE SENSOR
GRY/GRN WIRE
GRY/RED WIRE
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
INSTRUMENT CLUSTER
LO COOLANT LEVEL IND CTRL
LOGIC
LOW REF
RLY SPD SIG
SERIAL DATA
SPD SIG
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/BLK WIRE
Go to component -> Cooling fan circuit -> LO COOLANT LEVEL IND CTRL
