Chevrolet Silverado GMT K2XX facelift (2015-2019) keypad red Wiring diagram
This page shows the only wiring diagram for the component.keypad red, which is found in the car Chevrolet Silverado GMT K2XX facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram keypad red (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DATA 9 (+)
DRIVER DOOR LOCK SWITCH
DRIVER SEAT MEMORY SWITCH
DRIVER WINDOW SWITCH
GMLAN SERIAL
GREEN LED
GRN/BRN WIRE
GRN/WHT WIRE
GRY WIRE
HEATED STEERING WHEEL CONTROL MODULE
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSIDE REAR VIEW MIRROR
INSTRUMENT CLUSTER
INSTRUMENT PANEL JUNCTION BLOCK
IPC IGN/SDM IGN FUSE
KEYPAD
KEYPAD RED WIRE
LED
LED DISABLE SIG
LEFT INSTRUMENT PANEL FUSE BLOCK
LEFT STEERING WHEEL CONTROLS SWITCH
LO REF
LOGIC
LT GRN/YEL WIRE
OUTSIDE REAR VIEW MIRROR SWITCH
PARKING ASSIST CONTROL MODULE
PASSENGER AIR BAG DISABLED INDICATOR
PASSENGER DOOR LOCK SWITCH
RIGHT STEERING WHEEL CONTROLS SWITCH
SEAT MEMORY CONTROL MODULE
SERIAL DATA
STEERING WHEEL AIR BAG COIL
SWC BKLT FUSE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
VIO/WHT WIRE
W/ ACCESSORY STEERING WHEEL CONTROL
WHT WIRE
WHT/GRN WIRE
WHT/LT GRN WIRE
YEL WIRE
YEL/BRN WIRE
YEL/VIO WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> KEYPAD RED WIRE
