Chevrolet Silverado GMT K2XX facelift (2015-2019) front middle roof clearance lamp Wiring diagrams
This page contains all the electrical diagrams for the component. front middle roof clearance lamp, in which he is found in the car Chevrolet Silverado GMT K2XX facelift (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front middle roof clearance lamp (1 of 2)
BACKUP LAMPS CIRCUIT
BASE EQUIPMENT
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN/GRN WIRE
BRN/WHT WIRE
EXCEPT BASE EQUIPMENT
FRONT MIDDLE ROOF CLEARANCE LAMP
GMC
GRN/VIO WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BRN WIRE
GRY/GRN WIRE
LT GRN WIRE
NCA WIRE
RED/GRN WIRE
RIGHT BACKUP LAMP
RIGHT FRONT OUTER ROOF CLEARANCE LAMP
RIGHT FRONT REAR FENDER CLEARANCE LAMP
RIGHT INSTRUMENT PANEL FUSE BLOCK
RIGHT LOWER TAIL/STOP, TURN SIGNAL LAMP
RIGHT REAR FENDER CLEARANCE LAMP
RIGHT REAR SIDE MARKER LAMP
RIGHT TAIL LAMP ASSEMBLY
RIGHT TAIL/STOP, TURN SIGNAL LAMP
RIGHT UPPER TAIL/STOP, TURN SIGNAL LAMP
VIO/GRY WIRE
VIO/WHT WIRE
W/O SINGLE REAR WHEEL, RIDE, HANDLING CHASSIS W/ LED W/O LED
YEL/BLU WIRE
Go to component -> Exterior lamps circuit (4 of 7) -> FRONT MIDDLE ROOF CLEARANCE LAMP
Wiring diagram front middle roof clearance lamp (2 of 2)
ACCESSORY DC/AC POWER INVERTER MODULE
BASE EQUIPMENT EXCEPT BASE EQUIPMENT
BLK WIRE
BLOWER MOTOR
CARGO LAMP RELAY
CENTER CONSOLE COMPARTMENT ACCESSORY POWER RECEPTACLE
CENTER CONSOLE COMPARTMENT LAMP
CENTER CONSOLE REAR ACCESSORY POWER RECEPTACLE
CENTER HIGH MOUNTED STOP LAMP
CHILD SECURITY LOCK DISABLE RELAY
DATA LINK CONNECTOR
DOME LAMP SWITCH
DOOR DEAD LOCK RELAY
ELECTRICAL AUXILIARY HEATER
FIVE LAMP, ROOF MARKER
FRONT MIDDLE ROOF CLEARANCE LAMP
FRONT OVERHEAD CONSOLE LEFT DOME/ READING LAMPS
GARAGE DOOR OPENER
HORN SWITCH
INSIDE REAR VIEW MIRROR
INSTRUMENT PANEL 1 ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL 2 ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL JUNCTION BLOCK
LEFT FRONT OUTER ROOF CLEARANCE LAMP
LEFT STEERING WHEEL CONTROLS SWITCH
LEFT SUNSHADE
MOBILE DEVICE WIRELESS CHARGER MODULE
NCA WIRE
OVERHEAD CONSOLE ACCENT LAMP
PASSENGER AIR BAG DISABLED INDICATOR
RADIO PRESETS STEERING WHEEL CONTROLS SWITCH
RADIO VOLUME STEERING WHEEL CONTROLS SWITCH
RED WIRE
RETAINED ACCESSORY POWER RELAY 2
RIGHT FRONT OUTER ROOF CLEARANCE LAMP
RIGHT FRONT OVERHEAD CONSOLE DOME/ READING LAMPS
RIGHT STEERING WHEEL CONTROLS SWITCH
RIGHT SUNSHADE
ROOF BEACON PROVISION (BLUNT CUT)
ROOF BEACON RELAY
ROOF BEACON SWITCH
SLIDING REAR WINDOW CLOSE RELAY
SLIDING REAR WINDOW OPEN RELAY
SLIDING REAR WINDOW SWITCH
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATER
STEERING WHEEL HEATING CONTROL MODULE
SUNROOF MOTOR
SUNROOF SWITCH
TRANSFER CASE SHIFT CONTROL SWITCH
W/ HEATER STEERING WHEEL
W/ ROOF MOUNTED PROVISIONS LAMP W/ SUN ROOF GLASS SLIDING
WINDSHIELD FRONT VIEW CAMERA
YEL WIRE
Go to component -> Ground distribution circuit (4 of 6) -> FRONT MIDDLE ROOF CLEARANCE LAMP
