Chevrolet Silverado GMT K2XX facelift (2015-2019) cellular phone microphone Wiring diagrams

This page contains all the electrical diagrams for the component. cellular phone microphone, in which he is found in the car Chevrolet Silverado GMT K2XX facelift (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram cellular phone microphone (1 of 3)

Wiring diagram cellular phone microphone for Chevrolet Silverado GMT K2XX facelift (2015-2019) (1 of 3)

Get access

1-VT 2-VT AMP FUSE AUDIO SIG + BATT POS VOLT BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE CAMERA SIGNAL 2 CELL CELLULAR PHONE MICROPHONE CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX COMMUNICATION ENABLE COMPUTER DATA LINES SYSTEM DISPLAY SIG + GMLAN SERIAL DATA (+) 9 GPS GPS ANT SIG GPS/CELL GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES HUMAN MACHINE INTERFACE CONTROL MODULE (BEHIND GLOVE BOX) INFOTAINMENT INSTRUMENT PANEL JUNCTION BLOCK LOGIC LOW REF LT GRN/WHT WIRE LVDS MICROPHONE SIG MOST CONTROL MOST SERIAL DATA (+) NAVIGATION ANTENNA SIGNAL SPLITTER NCA WIRE NETWORK BUS 5 RED WIRE RED/VIO WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL FUSE BLOCK SER DATA TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE USB USB GY USB RECEPTACLE USB SERIAL DATA USB SRL DATA VOICE SIG W/ DIGITAL AUDIO SYSTEM W/ ONSTAR W/ ONSTAR W/O ONSTAR W/O ONSTAR WHT/BLU WIRE WHT/DK BLU WIRE WHT/GRN WIRE WHT/LT GRN WIRE WHT/VIO WIRE X-BK YEL WIRE

Go to component -> Navigation circuit, w/ amplifier (3 of 4) -> CELLULAR PHONE MICROPHONE

Wiring diagram cellular phone microphone (2 of 3)

Wiring diagram cellular phone microphone for Chevrolet Silverado GMT K2XX facelift (2015-2019) (2 of 3)

Get access

AUDIO LOW REF AUDIO SIG + BATT POS VOLT BK COAX AM/FM ANTENNA SIG BK COAX XM/HD BK LVDS INFOTAINMENT DISPLAY SIG BK USB USB SERIAL DATA BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/LT GRN WIRE CAMERA SIG 2 CELLULAR PHONE MICROPHONE COAX COMM SIG COMPUTER DATA LINES SYSTEM DET SIG DIGITAL RADIO ANTENNA DIM SIG DISPLAY RESET SIG DOWN SIG DOWN UP GMLAN SERIAL DATA GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES INFOTMNT FUSE LCD DIMMING SIG LF SPEAKER (-) CTRL 1 LH RR SPEAKER CTRL (+) LH RR SPEAKER SIG (-) LT AUD SIG 2 LVDS NAVIGATION SYSTEM NCA WIRE ON SIG RADIO RADIO ANTENNA RADIO PRESETS STEERING WHEEL CONTROLS SWITCH RADIO VOLUME STEERING WHEEL CONTROLS SWITCH RED WIRE RED/VIO WIRE REQUEST SIG RF SPEAKER (-) CTRL 1 RF SPEAKER SIG (-) 1 RH RR SPEAKER (+) CTRL RH RR SPEAKER SIG (-) RIGHT INSTRUMENT PANEL FUSE BLOCK RT AUD SIG 2 SCREEN 2 SWITCH SIG 2 USB USB/ OBS DET FUSE VIO WIRE VIO/GRY WIRE VOICE LOW VOICE SIG W/ ONSTAR W/O ONSTAR WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

Go to component -> Radio circuit, mid level (1 of 3) -> CELLULAR PHONE MICROPHONE
