6.6l vin 8, charging circuit for Chevrolet Silverado GMT K2XX (2013-2015)
6.6l vin 8, charging circuit
AUXILIARY GENERATOR (W/ DUAL GENERATOR, AMBULANCE UPFITTER)
BATTERY CURRENT SENSOR
BLK WIRE
BRN WIRE
CHARGE IND SIG
CHARGE INDICATOR
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC)
ENGINE COMPT NEAR FAN SHROUD)
ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF
GENERATOR B+
GENERATOR SIG
GM LAN SERIAL DATA
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
IPC FUSE 43
LOGIC
LOW SPEED
MEGA FUSE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/WHT WIRE
RIGHT BATTERY
SERIAL DATA (-) (1)
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE HOLDER (RIGHT SIDE OF FIREWALL)
VOLT
W/ DUAL GENERATOR, AMBULANCE UPFITTER
WHT WIRE
