6.0l vin g, charging circuit for Chevrolet Silverado GMT K2XX (2013-2015)

6.0l vin g, charging circuit

Get access

BATTERY CURRENT SENSOR BLK WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) BRN WIRE CHARGE IND SIG CHARGE LOW INDICATOR SPEED GM LAN SERIAL DATA LOGIC COMPUTER DATA LINES SYSTEM CURRENT SPLY DK GRN WIRE DRIVER INFORMATION CENTER (DIC) ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) GENERATOR B+ GENERATOR SIG GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) IPC FUSE 46 LOW REF MEGA FUSE NEAR FAN SHROUD) PNK WIRE POWER DISTRIBUTION SYSTEM POWER SUPPLY RED WIRE RED/WHT WIRE RIGHT BATTERY SENS SIG SERIAL DATA TAN/BLK WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) UNDERHOOD FUSE HOLDER (ON POSITIVE BATTERY TERMINAL) VOLT W/ 10 SERIES WHT WIRE
