Chevrolet Silverado GMT K2XX (2013-2015) w/o two speed transfer case Wiring diagram
This page shows the only wiring diagram for the component.w/o two speed transfer case, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o two speed transfer case (1 of 1)
2 3 LO SERIAL DATA HI SERIAL DATA
5 4 12 13 HI SPD GMLAN (+) HI SPD GMLAN (-) HI SPD GMLAN (-) HI SPD GMLAN (+)
6.0L (VIN B)
8600 GVM W/ ACTIVE BRAKE CONTROL
8600 GVW W/O ACTIVE BRAKE CONTROL
CAN BUS HI SERIAL DATA CAN BUS LOW SERIAL DATA
CNG CONTROL MODULE
COMM ENABLE SERIAL DATA
DATA LINK RESISTOR
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (ON LEFT SIDE OF FRAME ASSEMBLY)
EXCEPT 6.0L (VIN B)
FUEL PUMP FLOW CONTROL MODULE (REAR FRAME, NEAR SPARE TIRE MOUNT)
HI SPD GMLAN
HI SPD GMLAN SERIAL DATA
LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH)
LESS THAN 8600 GVM
LT BLU WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
SERIAL DATA
SERIAL DATA (-) HI SPD GMLAN
SERIAL DATA COMM ENABLE
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (BEHIND CENTER OF DASH)
W/ ACTIVE BRAKE CONTROL 10 SERIES W/ ACTIVE BRAKE CONTROL EXCEPT 10 SERIES
W/ ONSTAR
W/ TRAILER BRAKE
W/ TWO SPEED TRANSFER CASE
W/O INTEGRATED TRAILER BRAKE CONTROL
W/O ONSTAR
W/O TRAILER BRAKE
W/O TWO SPEED TRANSFER CASE
YAW RATE, LATERAL ACCELERATION SENSOR (UNDER CENTER CONSOLE TRIM PANEL)
YEL WIRE
YEL/BLK WIRE
Go to component -> Computer data lines circuit (2 of 3) -> W/O TWO SPEED TRANSFER CASE
