Chevrolet Silverado GMT K2XX (2013-2015) w/ media disc player w/o media disc player except base base Wiring diagram
This page shows the only wiring diagram for the component.w/ media disc player w/o media disc player except base base, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ media disc player w/o media disc player except base base (1 of 1)
2 1 MOST SER DATA (+) MOST SER DATA (-)
2 3 MOST SER DATA (-) MOST SER DATA (+)
3 4 MOST SER DATA (-) MOST SER DATA (+)
8 9 MOST SER DATA (+) MOST SER DATA (-)
DK BLU WIRE
DK BLU/YEL WIRE
GRN/WHT WIRE
GRY/VIO WIRE
HUMAN MACHINE INTERFACE CONTROL MODULE (BEHIND THE GLOVE BOX)
HVAC CONTROL MODULE (BEHIND THE
INFO DISPLAY MODULE
LINEAR INTERCONNECT
LINEAR INTERCONNECT NETWORK BUS 10
LO SPD GMLAN SER DATA
LT GRN WIRE
LT GRN/DK BLU WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
MOST CTRL
NETWORK BUS 10 LINEAR INTERCONNECT
NETWORK BUS 5
NETWORK BUS 5 LINEAR INTERCONNECT
NETWORK BUS 9
NETWORK BUS 9 LINEAR INTERCONNECT
RADIO
SER DATA LO SPD GMLAN
UPPER GLOVE BOX)
VIO/YEL WIRE
W/ MEDIA DISC PLAYER W/O MEDIA DISC PLAYER EXCEPT BASE BASE
WHT WIRE
WHT/DK BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
Go to component -> Computer data lines circuit (2 of 5) -> W/ MEDIA DISC PLAYER W/O MEDIA DISC PLAYER EXCEPT BASE BASE
