Chevrolet Silverado GMT K2XX (2013-2015) vnt open sig Wiring diagram
This page shows the only wiring diagram for the component.vnt open sig, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vnt open sig (1 of 1)
ACC VOLT
BLK WIRE
BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) VOLT
BRN WIRE
BRN/WHT WIRE
CLOSE
CREW CAB
DK GRN WIRE
EXPRESS CLOSE (CREW CAB)
EXPRESS OPEN
GASOLINE DIESEL
GROUND
HOT AT ALL TIMES
ILLUMINATION LAMP
LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH)
ORG/ WIRE
ORG/BLK WIRE
PNK VNT CLOSE SIG WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
RIGHT I/P JUNCTION BLOCK (IN RIGHT END OF DASH)
ROOF CLOSE SIG
ROOF OPEN SIG
S/ROOF FUSE 34 FUSE 31
SUNROOF MODULE
SUNROOF MOTOR
SUNROOF SWITCH
SW XPRS SIG
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT)
VENT
VNT OPEN SIG
YEL WIRE
Go to component -> Power top/sunroof circuit -> VNT OPEN SIG
