Chevrolet Silverado GMT K2XX (2013-2015) vehicle inclination sensor vehicle shock sensor Wiring diagrams
This page contains all the electrical diagrams for the component. vehicle inclination sensor vehicle shock sensor, in which he is found in the car Chevrolet Silverado GMT K2XX (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram vehicle inclination sensor vehicle shock sensor (1 of 2)
6.0L (VIN G)
A/C CMPRSR RELAY
BANK 1 SENSOR 1
BANK 1 SENSOR 2
BANK 2 SENSOR 1
BANK 2 SENSOR 2
COMFORT, DECOR LEVEL 3 CONVENIENCE PACKAGE, W/ LUXURY
EAP FUSE 38
ECM/THROT CONT FUSE 5
ELECTRONIC ADJUSTABLE PEDALS PCB RELAY
ENG FUSE 4
ENGINE CONTROL MODULE (ECM)
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE SOLENOID VALVE
EXCEPT 6.0L
FAN CNTRL RELAY
FAN HI RELAY FAN-2 FUSE 60
FAN LO RELAY
FAN-1 FUSE 57
FROM FRT WPR FUSE 36 (DIAGRAM 5 OF 7)
FUEL FUEL INJECTOR INJECTOR
FUEL INJECTOR
FUSE 52
HEATED OXYGEN SENSOR
IGNITION COIL 1
IGNITION FUEL COIL 7 INJECTOR
IGNITION IGNITION COIL 3 COIL 5 FROM LEFT I/P J/B (DIAGRAM 5 OF 7)
INJ-A FUSE 24
LEFT I/P J/B (LOWER LEFT SIDE OF DASH)
MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR
NCA WIRE
PARK ENABLE PCB RELAY
PNK WIRE
PNK/BLK WIRE
POWER TAKE OFF (PTO) CONTROLS
POWER TAKE OFF (PTO) MODULE (IF EQUIPPED)
POWER TAKE OFF (PTO) PROVISION (BLUNT CUT)
PWR/ TRN RELAY
REARVIEW CAMERA IMAGE DISPLAY MODULE
RED WIRE
RED/WHT WIRE
SECURITY INDICATOR LAMP
SNSR FUSE 18
SNSR FUSE 8
TO AUXILIARY BATTERY RUN RELAY (DIAGRAM 1 OF 7)
TO INJ-B FUSE 13 (DIAGRAM 7 OF 7)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VALVE LIFTER OIL MANIFOLD (VLOM) ASSEMBLY (6.0 L)
VEHICLE INCLINATION SENSOR VEHICLE SHOCK SENSOR
W/ 10 SERIES
W/ AUXILIARY BATTERY
W/ REAR VIEW CAMERA
W/O ENGINE CONTROL POWER TAKE OFF (PTO) CONTROLS W/ ENGINE CONTROL
W/O REAR VIEW CAMERA
YEL WIRE
Go to component -> 6.0l vin b, power distribution circuit (6 of 7) -> VEHICLE INCLINATION SENSOR VEHICLE SHOCK SENSOR
Wiring diagram vehicle inclination sensor vehicle shock sensor (2 of 2)
6.0L (VIN G)
A/C CMPRSR RELAY
BANK 1 SENSOR 1
BANK 1 SENSOR 2
BANK 2 SENSOR 1
BANK 2 SENSOR 2
COMFORT, DECOR LEVEL 3 CONVENIENCE PACKAGE, W/ LUXURY
EAP FUSE 38
ECM/THROT CONT FUSE 5
ELECTRONIC ADJUSTABLE PEDALS PCB RELAY
ENG FUSE 4
ENGINE CONTROL MODULE (ECM)
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE SOLENOID VALVE
EXCEPT 6.0L
FAN CNTRL RELAY
FAN HI RELAY FAN-2 FUSE 60
FAN LO RELAY
FAN-1 FUSE 57
FROM FRT WPR FUSE 36 (DIAGRAM 5 OF 7)
FUEL FUEL INJECTOR INJECTOR
FUEL INJECTOR
FUSE 52
HEATED OXYGEN SENSOR
IGNITION COIL 1
IGNITION FUEL COIL 7 INJECTOR
IGNITION IGNITION COIL 3 COIL 5 FROM LEFT I/P J/B (DIAGRAM 5 OF 7)
INJ-A FUSE 24
LEFT I/P J/B (LOWER LEFT SIDE OF DASH)
MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR
NCA WIRE
PARK ENABLE PCB RELAY
PNK WIRE
PNK/BLK WIRE
POWER TAKE OFF (PTO) CONTROLS
POWER TAKE OFF (PTO) MODULE (IF EQUIPPED)
POWER TAKE OFF (PTO) PROVISION (BLUNT CUT)
PWR/ TRN RELAY
REARVIEW CAMERA IMAGE DISPLAY MODULE
RED WIRE
RED/WHT WIRE
SECURITY INDICATOR LAMP
SNSR FUSE 18
SNSR FUSE 8
TO AUXILIARY BATTERY RUN RELAY (DIAGRAM 1 OF 7)
TO INJ-B FUSE 13 (DIAGRAM 7 OF 7)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VALVE LIFTER OIL MANIFOLD (VLOM) ASSEMBLY (6.0 L)
VEHICLE INCLINATION SENSOR VEHICLE SHOCK SENSOR
W/ 10 SERIES
W/ AUXILIARY BATTERY
W/ REAR VIEW CAMERA
W/O ENGINE CONTROL POWER TAKE OFF (PTO) CONTROLS W/ ENGINE CONTROL
W/O REAR VIEW CAMERA
YEL WIRE
Go to component -> 6.0l vin g, power distribution circuit (6 of 7) -> VEHICLE INCLINATION SENSOR VEHICLE SHOCK SENSOR
