Chevrolet Silverado GMT K2XX (2013-2015) twilight sentinel delay signal Wiring diagram
This page shows the only wiring diagram for the component.twilight sentinel delay signal, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram twilight sentinel delay signal (1 of 1)
5 VOLT REFERENCE REAR AIR TEMP DOOR CTRL REAR DEFOG RLY CTRL
AMBIENT LIGHT/ SUNLOAD SENSOR (TOP CENTER OF DASH)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MTR
BLOWER MTR SPD CTRL
BLU/GRY WIRE
BLU/WHT WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DK BLU/BRN WIRE
DK BLU/YEL WIRE
FRT BLWR FUSE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/RED WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
HVAC CONTROL MODULE (BEHIND THE UPPER GLOVE BOX)
HVAC/AUX HVAC IGN FUSE
INSIDE AIR TEMP SENS SIG
INSTRUMENT PANEL JUNCTION BLOCK
LEFT INSTRUMENT PANEL FUSE BLOCK
LINEAR INTERCONNECT NETWORK BUS 9
LOGIC
LT GRN WIRE
LT GRN/YEL WIRE
PEPS/HVAC FUSE
RED/VIO WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
SOLAR SENSOR DRIVER SIGNAL
SPD CTRL
TWILIGHT SENTINEL DELAY SIGNAL
VIO/GRY WIRE
VOLT BATT POSITIVE
WHT/DK BLU WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit (1 of 4) -> TWILIGHT SENTINEL DELAY SIGNAL
