Chevrolet Silverado GMT K2XX (2013-2015) trlr bck/up fuse 10 fuse 9 Wiring diagrams
This page contains all the electrical diagrams for the component. trlr bck/up fuse 10 fuse 9, in which he is found in the car Chevrolet Silverado GMT K2XX (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trlr bck/up fuse 10 fuse 9 (1 of 2)
10 11 HIGH SPEED BUS (+)
6.6L CHEVROLET GMC
AUTOMATIC TRANSMISSION (6.6L)
AUTOMATIC TRANSMISSION FLUID PRESSURE (TFP) MANUAL VALVE
AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS)
AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) AUTOMATIC TRANSMISSION ( 6.0L)
BCK/UP LAMP PCB RELAY
BCK/UP RLY
BCK/UP SIG
BCM FUSE 15
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL TRANSMISSION SOLENOID CONTROL VALVE MODULE ASSEMBLY (TCM)
CONVENIENCE PACKAGE
DASH)
DATA BUS -
DK BLU WIRE
DK GRN WIRE
GMLAN SERIAL HI SPD
GRD
GRN WIRE
GROUND DISTRIBUTION
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HIGH SPEED BUS -
HOT AT ALL TIMES I/P FUSE BLOCK (LEFT SIDE OF
INSIDE REARVIEW MIRROR (ISRVM)
LEFT BACKUP LAMP
LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH)
LEFT LOWER TAIL/STOP, TURN SIGNAL LAMP
LEFT UPPER TAIL/STOP, TURN SIGNAL LAMP
LOW REF
LOW SPEED 10 3 5 SERIAL DATA B+ GND
LT GRN WIRE
MJR
NCA WIRE
PNK/BLK WIRE
POSITION SWITCH)
POWER DISTRIBUTION SYSTEM
REAR LAMPS JUNCTION BLOCK (INSIDE OF LEFT REAR FRAME RAIL)
REARVIEW CAMERA (LEFT OF TAILGATE HANDLE)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT LOWER TAIL/STOP, TURN SIGNAL LAMP
RIGHT UPPER TAIL/STOP, TURN SIGNAL LAMP
SW SIG A
SW SIG B
SW SIG C
SW SIG P
SYSTEM
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRAILER TOW CIRCUIT
TRANS RANGE SIG A
TRANS RANGE SIG B
TRANS RANGE SIG C
TRANSMISSION CONTROL MODULE (TCM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD)
TRLR BCK/UP FUSE 10 FUSE 9
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VEH BCK/UP FUSE 15 FUSE 14
W/ COMFORT, DECOR LEVEL 3
W/ REARVIEW CAMERA
W/ SPO REARVIEW CAMERA
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Backup lamps circuit -> TRLR BCK/UP FUSE 10 FUSE 9
Wiring diagram trlr bck/up fuse 10 fuse 9 (2 of 2)
ANTI-LOCK BRAKES SYSTEM
BACKUP LAMPS CIRCUIT
BLK WIRE
BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH)
BRN WIRE
CAMPER TRAILER BLUNT CUTS
CUT)
DK BLU WIRE
DK GRN WIRE
EXTERIOR LIGHTS CIRCUIT
HOT AT ALL TIMES
HOT W/ BCK/UP LAMP RELAY ENERGIZED
HOT W/ PARK LAMP RELAY ENERGIZED
LEFT REAR FRAME RAIL) (31 SERIES: ON LEFT FRAME RAIL)
LT BLU/WHT WIRE
LT GRN WIRE
LT TRAILER TURN SIG LMP
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RED/BLK WIRE
RT TRAILER TURN SIG LMP
STUD 1 FUSE 68 FUSE 63
STUD 2 FUSE 63 FUSE 58
TRAILER BRAKE CONTROLLER SOLID STATE RELAY (20/30 SERIES:
TRAILER CONNECTOR (W/ TRUCK TRAILER WIRING HARNESS) (AT REAR OF VEHICLE)
TRAILER PROVISION (BLUNT
TRLR BCK/UP FUSE 10 FUSE 9
TRLR LT STOP/TURN PCB RELAY
TRLR PRK FUSE 25 FUSE 22
TRLR RT STOP/TURN PCB RELAY
TRLR STOP LT FUSE 3 FUSE 2
TRLR STOP RT FUSE 1 FUSE 4
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/O TRAILER BRAKE CONTROL
WHEEL TRAILER WIRING PROVISIONS, 97 DECIBELS ELECTRICAL BACKUP ALARM
WHT WIRE
YEL WIRE
Go to component -> Trailer tow circuit -> TRLR BCK/UP FUSE 10 FUSE 9
