Chevrolet Silverado GMT K2XX (2013-2015) snsr sig Wiring diagram
This page shows the only wiring diagram for the component.snsr sig, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram snsr sig (1 of 1)
2-HI IND
4-HI IND
4-LO IND
BLK WIRE
BLK/LT GRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DATA 1 (+)
DK BLU WIRE
DK BLU/YEL WIRE
ENGINE BLOCK)
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD)
GRY/LT GRN WIRE
GRY/RED WIRE
IGN 3
ILL
INSTRUMENT PANEL JUNCTION BLOCK
LOW REF
LT GRN/BLK WIRE
NEUTRAL IND
RED/GRY WIRE
SERIAL
SERIAL DATA (-) (1)
SNSR SIG
TRANSFER CASE MOTOR (ON TRANSFER CASE)
TRANSFER CASE SHIFT CONTROL SWITCH (ON TOP LEFT OF TRANSFER CASE)
TRANSMISSION OUTPUT SHAFT SPEED SENSOR (IN TRANSMISSION)
VEH SPD
VEH SPD SNSR
VIO WIRE
VIO/BRN WIRE
VIO/LT GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/LT GRN WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Transfer case circuit, 2-speed with push button control (2 of 2) -> SNSR SIG
