Chevrolet Silverado GMT K2XX (2013-2015) sliding rear window switch Wiring diagrams
This page contains all the electrical diagrams for the component. sliding rear window switch, in which he is found in the car Chevrolet Silverado GMT K2XX (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sliding rear window switch (1 of 2)
ACCESSORY DC/AC PANEL 2 POWER ACCESSORY INVERTER POWER MODULE RECEPTACLE
BLK WIRE
BRN WIRE
CENTER CONSOLE COMPARTMENT LAMP
CENTER HIGH MOUNTED STOP LAMP
DATA LINK CONNECTOR
DOME LAMP SWITCH
DOME/ READING LAMPS
FRONT OVERHEAD CONSOLE LEFT DOME/ READING LAMPS
FRONT OVERHEAD CONSOLE RIGHT DOME/ READING LAMPS
FRONT VIEW CAMERA MODULE
GARAGE DOOR OPENER
HORN SWITCH
INSIDE REARVIEW MIRROR
INSTRUMENT INSTRUMENT PANEL 1 ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL 3 ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL JUNCTION BLOCK
LEFT STEERING WHEEL CONTROLS SWITCH
LEFT SUNSHADE MIRROR LAMP
OVERHEAD CONSOLE ACCENT LAMP
PASSENGER AIR BAG DISABLED INDICATOR
POLICE PROVISION (BLUNT CUT)
RADIO PRESETS STEERING WHEEL CONTROLS SWITCH
RADIO VOLUME STEERING WHEEL CONTROLS SWITCH
RIGHT INSTRUMENT PANEL FUSE BLOCK
RIGHT STEERING WHEEL CONTROLS SWITCH
RIGHT SUNSHADE MIRROR LAMP
ROOF BEACON SWITCH
ROOF BLOWER BEACON MOTOR RELAY
SLIDING REAR WINDOW CLOSE RELAY
SLIDING REAR WINDOW OPEN RELAY
SLIDING REAR WINDOW SWITCH
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATER
STEERING WHEEL HEATING CONTROL MODULE
SUNROOF MOTOR
SUNROOF SWITCH
Go to component -> Ground distribution circuit (3 of 5) -> SLIDING REAR WINDOW SWITCH
Wiring diagram sliding rear window switch (2 of 2)
ACCES- SORY VOLTAGE
BLK WIRE
BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH)
BRN/WHT WIRE
CLOSE
HOT AT ALL TIMES
ILLUMI- NATION
LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH)
POWER DISTRIBUTION SYSTEM
PPL
PWR REAR WNDW CIRCUIT BREAKER
RED WIRE
RED/WHT WIRE
SLIDING REAR WINDOW CLOSE RELAY
SLIDING REAR WINDOW MOTOR (RIGHT REAR OF PASSENGER COMPT)
SLIDING REAR WINDOW OPEN RELAY
SLIDING REAR WINDOW SWITCH
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Sliding rear window circuit -> SLIDING REAR WINDOW SWITCH
