Chevrolet Silverado GMT K2XX (2013-2015) serial data comm enable lf rr whl spd snsr sply volt lf rear wheel spd snsr sig Wiring diagram
This page shows the only wiring diagram for the component.serial data comm enable lf rr whl spd snsr sply volt lf rear wheel spd snsr sig, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram serial data comm enable lf rr whl spd snsr sply volt lf rear wheel spd snsr sig (1 of 1)
ABS PUMP FUSE
ABS VLV FUSE
BLK WIRE
BLK/YEL WIRE
BRAKE PRESSURE MODULATOR
BRAKE VACUUM SNSR LOW REF BATT POSITIVE VOLT
CMBD VHCE IN SNSR SPLY VOLT BRAKE FLUID LEVEL SNSR SIGL
COMPUTER DATA LINES SYSTEM
COMPUTER DATALINES SYSTEM
DK BLU WIRE
DK BLU/YEL WIRE
ELECTRONIC BRAKE CONTROL MODULE (ON LEFT SIDE OF FRAME ASSEMBLY)
GMLAN
GMLAN SERIAL DATA (-) (1) GMLAN SERIAL DATA (+) (1)
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL JUNCTION BLOCK
LEFT FRONT WHEEL SPEED SENSOR (ON LEFT FRONT STEERING KNUCKLE)
LEFT REAR WHEEL SPEED SENSOR (ON LEFT REAR BRAKE BACKING PLATE)
LT GRN/BRN WIRE
LT GRN/GRY WIRE
NCA WIRE
RED/VIO WIRE
RED/YEL WIRE
SENS SPLY VOLT
SERIAL DATA COMM ENABLE LF RR WHL SPD SNSR SPLY VOLT LF REAR WHEEL SPD SNSR SIG
STEERING ANGLE SENSOR (ON STEERING COLUMN)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VIO WIRE
WHT WIRE
WHT/DK BLU WIRE
YEL WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> SERIAL DATA COMM ENABLE LF RR WHL SPD SNSR SPLY VOLT LF REAR WHEEL SPD SNSR SIG
