Chevrolet Silverado GMT K2XX (2013-2015) right rear door speaker Wiring diagrams
This page contains all the electrical diagrams for the component. right rear door speaker, in which he is found in the car Chevrolet Silverado GMT K2XX (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear door speaker (1 of 3)
2 1 RF SPKR (+) (1) SPEAKER +
6 5 4 3 RF SPKR (-) (1) SPEAKER - BATT POS VOLT LF SPKR (+) (1)
8 7 GROUND LF SPKR (-) (1)
AUDIO AMPLIFIER (UNDER REAR OF CENTER CONSOLE)
BLK WIRE
BLK/ YEL WIRE
BLU (OR DK BLU) WIRE
BLU WIRE
BLU/ YEL WIRE
BRN/BLU (OR BRN/DK BLU) WIRE
BRN/BLU WIRE
BRN/DK BLU (OR YEL/GRY) WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU (OR YEL/BLU) WIRE
DK BLU BRN/ WIRE
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/GRY WIRE
DK BLU/YEL WIRE
ENGINE CONTROLS SYSTEM COMPUTER DATA LINES SYSTEM
GRY YEL/ WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/VIO WIRE
LEFT FRONT DOOR SPEAKER
LEFT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE
LEFT INSTRUMENT PANEL SPEAKER
LR SPK (+) RR SPK (+) LF SPK (+) RF SPK (+)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/BRN WIRE
MICROPHONE 3 SIG MICROPHONE 2 SIG MICROPHONE 1 SIG
MOST CONTROL
NCA WIRE
REAR RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE
RED/YEL WIRE
REPLICATED SIG GMLAN SERIAL DATA
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE
RIGHT INSTRUMENT PANEL SPEAKER
RIGHT REAR DOOR SPEAKER
SERIAL DATA - SERIAL DATA + SERIAL DATA + SERIAL DATA -
SUBWOOFER DOOR SPEAKER
VIO/BRN WIRE
VIO/DK BLU WIRE
W/ PREMIUM SURROUND AMPLIFIER
W/O PREMIUM SURROUND AMPLIFIER
WHT WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL (OR BRN/GRN) WIRE
YEL WIRE
YEL/BLK (OR VIO/BRN) WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Navigation circuit (4 of 4) -> RIGHT REAR DOOR SPEAKER
Wiring diagram right rear door speaker (2 of 3)
2 1 RF SPKR (+) (1) SPEAKER +
6 5 4 3 RF SPKR (-) (1) SPEAKER - BATT POS VOLT LF SPKR (+) (1)
8 7 GROUND LF SPKR (-) (1)
AUDIO AMPLIFIER (UNDER REAR OF CENTER CONSOLE)
BLK WIRE
BLK/ YEL WIRE
BLU (OR DK BLU) WIRE
BLU WIRE
BLU/ YEL WIRE
BRN/BLU (OR BRN/DK BLU) WIRE
BRN/BLU WIRE
BRN/DK BLU (OR YEL/GRY) WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU (OR YEL/BLU) WIRE
DK BLU BRN/ WIRE
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/GRY WIRE
DK BLU/YEL WIRE
ENGINE CONTROLS SYSTEM COMPUTER DATA LINES SYSTEM
GRY YEL/ WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/VIO WIRE
LEFT FRONT DOOR SPEAKER
LEFT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE
LEFT INSTRUMENT PANEL SPEAKER
LR SPK (+) RR SPK (+) LF SPK (+) RF SPK (+)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/BRN WIRE
MICROPHONE 3 SIG MICROPHONE 2 SIG MICROPHONE 1 SIG
MOST CONTROL
NCA WIRE
REAR RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE
RED/YEL WIRE
REPLICATED SIG GMLAN SERIAL DATA
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE
RIGHT INSTRUMENT PANEL SPEAKER
RIGHT REAR DOOR SPEAKER
SERIAL DATA - SERIAL DATA + SERIAL DATA + SERIAL DATA -
SUBWOOFER DOOR SPEAKER
VIO/BRN WIRE
VIO/DK BLU WIRE
W/ PREMIUM SURROUND AMPLIFIER
W/O PREMIUM SURROUND AMPLIFIER
WHT WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL (OR BRN/GRN) WIRE
YEL WIRE
YEL/BLK (OR VIO/BRN) WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Radio circuit, with navigation (4 of 4) -> RIGHT REAR DOOR SPEAKER
Wiring diagram right rear door speaker (3 of 3)
