Chevrolet Silverado GMT K2XX (2013-2015) replicated tos signal Wiring diagrams
This page contains all the electrical diagrams for the component. replicated tos signal, in which he is found in the car Chevrolet Silverado GMT K2XX (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram replicated tos signal (1 of 3)
13 14 15 STOP LAMP SW SIG SENSOR LOW REF VOLT REFERENCE
6.0L (VIN G)
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR SIGNAL
AUX HVAC- IGN FUSE 45
BATT GND
BLK/WHT WIRE
BRAKE PEDAL POSITION (BPP) SENSOR
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DASH)
DK BLU WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY INSTRUMENT CLUSTER PANEL (IPC)
ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD)
EXCEPT 6.0L (VIN G)
FUSE 19
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT W/ RUN/CRNK RELAY ENERGIZED
IGN
LOGIC
LOW REFERENCE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/BLK WIRE
PC SOLENOID 1 CONTROL
PC SOLENOID 2 CONTROL
PC SOLENOID 3 CONTROL
PC SOLENOID 4 CONTROL
PC SOLENOID 5 CONTROL
PNK IGN WIRE
PNK WIRE
PPL/WHT WIRE
PRESSURE CONTROL (PC) SOLENOID VALVE 1
PRESSURE CONTROL (PC) SOLENOID VALVE 2
PRESSURE CONTROL (PC) SOLENOID VALVE 3
PRESSURE CONTROL (PC) SOLENOID VALVE 4
PRESSURE CONTROL (PC) SOLENOID VALVE 5
RED/WHT WIRE
REPLICATED TOS SIGNAL
SHIFT SOLENOID (SS) 1 CONTROL
SHIFT SOLENOID (SS) 2 CONTROL
SHIFT SOLENOID (SS) VALVE 1
SHIFT SOLENOID (SS) VALVE 2
TAN WIRE
TAN/BLK WIRE
TCM- BATT FUSE 14
TO AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) (DIAGRAM 2 OF 2)
TORQUE CONVERTER CLUTCH (TCC) PRESSURE CONTROL (PC) SOLENOID VALVE
TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL
TOS SIG
TOW/ HAUL IND
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VEHICLE SPEED SENSOR (VSS) (ON TRANSFER CASE TAILSHAFT HOUSING)
VSS HIGH SIG
VSS LOW SIG
Go to component -> 6.0l vin b, a/t circuit (1 of 2) -> REPLICATED TOS SIGNAL
Wiring diagram replicated tos signal (2 of 3)
13 14 15 STOP LAMP SW SIG SENSOR LOW REF VOLT REFERENCE
6.0L (VIN G)
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR SIGNAL
AUX HVAC- IGN FUSE 45
BATT GND
BLK/WHT WIRE
BRAKE PEDAL POSITION (BPP) SENSOR
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DASH)
DK BLU WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY INSTRUMENT CLUSTER PANEL (IPC)
ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD)
EXCEPT 6.0L (VIN G)
FUSE 19
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT W/ RUN/CRNK RELAY ENERGIZED
IGN
LOGIC
LOW REFERENCE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/BLK WIRE
PC SOLENOID 1 CONTROL
PC SOLENOID 2 CONTROL
PC SOLENOID 3 CONTROL
PC SOLENOID 4 CONTROL
PC SOLENOID 5 CONTROL
PNK IGN WIRE
PNK WIRE
PPL/WHT WIRE
PRESSURE CONTROL (PC) SOLENOID VALVE 1
PRESSURE CONTROL (PC) SOLENOID VALVE 2
PRESSURE CONTROL (PC) SOLENOID VALVE 3
PRESSURE CONTROL (PC) SOLENOID VALVE 4
PRESSURE CONTROL (PC) SOLENOID VALVE 5
RED/WHT WIRE
REPLICATED TOS SIGNAL
SHIFT SOLENOID (SS) 1 CONTROL
SHIFT SOLENOID (SS) 2 CONTROL
SHIFT SOLENOID (SS) VALVE 1
SHIFT SOLENOID (SS) VALVE 2
TAN WIRE
TAN/BLK WIRE
TCM- BATT FUSE 14
TO AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) (DIAGRAM 2 OF 2)
TORQUE CONVERTER CLUTCH (TCC) PRESSURE CONTROL (PC) SOLENOID VALVE
TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL
TOS SIG
TOW/ HAUL IND
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VEHICLE SPEED SENSOR (VSS) (ON TRANSFER CASE TAILSHAFT HOUSING)
VSS HIGH SIG
VSS LOW SIG
Go to component -> 6.0l vin g, a/t circuit (1 of 2) -> REPLICATED TOS SIGNAL
Wiring diagram replicated tos signal (3 of 3)
7 1 2 IGN DATA (-) DATA (+)
AUTOMATIC TRANSMISSION ASSEMBLY
AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR SIGNAL
BATT GND
BLK WIRE
BLK/WHT WIRE
BRN/WHT WIRE
COMPT, NEAR FAN SHROUD)
COMPUTER 5985 2500 2501 2139 2501 2500 DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DK BLU WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY LOGIC INSTRUMENT CLUSTER
ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE
GRY/PPL WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
IGN
IPC FUSE BLOCK FUSE (LOWER LEFT SIDE OF DASH)
LOW REFERENCE
PARK/NEUTRAL SIG GMLAN DATA BUS (-) GMLAN DATA BUS (+)
PC SOLENOID 1 CONTROL
PC SOLENOID 2 CONTROL
PC SOLENOID 3 CONTROL
PC SOLENOID 4 CONTROL
PC SOLENOID 5 CONTROL
POWER DISTRIBUTION SYSTEM
PRESSURE CONTROL (PC) SOLENOID VALVE 1
PRESSURE CONTROL (PC) SOLENOID VALVE 2
PRESSURE CONTROL (PC) SOLENOID VALVE 3
PRESSURE CONTROL (PC) SOLENOID VALVE 4
PRESSURE CONTROL (PC) SOLENOID VALVE 5
RED/GRY WIRE
RED/LT GRN WIRE
REPLICATED TOS SIGNAL
SHIFT SOLENOID (SS) 1 CONTROL
SHIFT SOLENOID (SS) 2 CONTROL
SHIFT SOLENOID (SS) VALVE 1
SHIFT SOLENOID (SS) VALVE 2
TCM/ECM FUSE
TO TRANSMISSION INTERNAL MODE SWITCH (IMS) (DIAGRAM 2 OF 2)
TORQUE CONVERTER CLUTCH (TCC) PRESSURE CONTROL (PC) SOLENOID VALVE
TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL
TOS SIG
TOW/ HAUL IND
TRANS IGN FUSE 40
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VIO/BLK WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRN WIRE
WHT/GRY WIRE
Go to component -> A/t circuit (1 of 2) -> REPLICATED TOS SIGNAL
