Chevrolet Silverado GMT K2XX (2013-2015) prk lmp lt fuse Wiring diagram
This page shows the only wiring diagram for the component.prk lmp lt fuse, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram prk lmp lt fuse (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CHMSL FUSE
DK BLU WIRE
DK GRN WIRE
GRN/VIO WIRE
GRY/BRN WIRE
HEADLIGHTS SYSTEM
LT BLU WIRE
LT GRN LT BLU WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
PRK LMP LT FUSE
PRK LMP RT FUSE
REAR BODY JUNCTION BLOCK
RED WIRE
RED/LT GRN WIRE
RIGHT FRONT PARK LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT LOWER PARK/TURN SIGNAL LAMP
RIGHT MULTI-FUNCTION LED CONTROL MODULE HEADLAMP
RIGHT PARK DAYTIME RUNNING LAMP
RIGHT PARK/TURN SIGNAL LAMP
RIGHT UPPER PARK/TURN SIGNAL LAMP
STOP LAMP RELAY
TRAILER PARK LAMPS RELAY
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Exterior lamps circuit (3 of 4) -> PRK LMP LT FUSE
