Chevrolet Silverado GMT K2XX (2013-2015) pnk supplemental restraints system Wiring diagram
This page shows the only wiring diagram for the component.pnk supplemental restraints system, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk supplemental restraints system (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 B+
B+ LOW REF LO SPD DATA
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL ASSEMBLY)
CHIME MODULE (CENTER OF DASH, BEHIND RADIO)
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONNECTOR BREAKOUT) (W/ LUXURY EDITION)
DK BLU WIRE
DK GRN WIRE
DLIS FUSE 35 FUSE 32
DRIVER INFORMATION CENTER (DIC) DISPLAY
DRIVER SEAT BELT BUCKLE
DRIVER SEAT BELT SWITCH
EXCEPT 6.6L 6.6L
HOT AT ALL TIMES
IGNITION SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER DRIVER'S SEAT)
INSTRUMENT PANEL CLUSTER (IPC) LOW OIL IND
IPC FUSE 46 FUSE 43
KEY-IN IGNITION SWITCH
LEFT I/P JUNCTION BLOCK (LOWER LEFT
LEFT SEAT BELT SW
LO SPD GMLAN SERIAL DATA
LOGIC
LOW REF
LT BLU WIRE
NCA WIRE
OFF
PARK BRAKE SWITCH (ON PARK
PNK SUPPLEMENTAL RESTRAINTS SYSTEM WIRE
PNK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RADIO
RDO FUSE 42 FUSE 39
RED/WHT WIRE
RUN WIRE
SEAT BRAKE BELT IND IND
SERIAL DATA
SIDE OF DASH)
SOUND SYSTEMS
SYSTEM
TAN WIRE
TAN/WHT WIRE
TIRE PRESSURE IND
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/ RADIO PROVISIONS
W/ UYS W/O UYS
W/O LUXURY EDITION
W/O RADIO PROVISIONS
WHT WIRE
Go to component -> Warning systems circuit, with bucket seats & power mirrors (2 of 2) -> PNK SUPPLEMENTAL RESTRAINTS SYSTEM WIRE
