Chevrolet Silverado GMT K2XX (2013-2015) passenger seat position sensor Wiring diagrams
This page contains all the electrical diagrams for the component. passenger seat position sensor, in which he is found in the car Chevrolet Silverado GMT K2XX (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger seat position sensor (1 of 2)
1 1 RF HEAD CURTAIN MOD HI CTRL RF HEAD CURTAIN MOD LO CTRL
BLK/ORG WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
DK GRN WIRE
DRIVER SEAT BELT ANCHOR PRETENSIONER
DRIVER SEAT BELT RETRACTOR PRETENSIONER
DRIVER SEAT BELT SWITCH DRIVER SEAT BELT BUCKLE
DRIVER SEAT POSITION SENSOR
DRIVER SEAT SIDE AIR BAG
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER DRIVER'S SEAT)
LT BLU WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/LT GRN WIRE
ORG/VIO WIRE
ORG/YEL WIRE
PASSENGER SEAT BELT ANCHOR PRETENSIONER
PASSENGER SEAT BELT RETRACTOR PRETENSIONER
PASSENGER SEAT BELT SWITCH PASSENGER SEAT BELT BUCKLE
PASSENGER SEAT POSITION SENSOR
PASSENGER SEAT SIDE AIR BAG
RED WIRE
RIGHT ROOF RAIL AIR BAG
SHORTING BAR
VIO/ORG WIRE
WHT WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> PASSENGER SEAT POSITION SENSOR
Wiring diagram passenger seat position sensor (2 of 2)
18 20 GMLAN SER DATA (+) GMLAN SER DATA (-)
BCM 3 FUSE
BLK WIRE
BLK/ORG WIRE
BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER RESERVOIR)
BRAKE IND
BREAKOUT)
BRK FLUID LVL
COMPUTER DATA LINES SYSTEM
DISPLAY
DK BLU WIRE
DK BLU/YEL WIRE
DLIS FUSE
DRIVER SEAT BELT SWITCH DRIVER SEAT BELT BUCKLE
DRIVER SEAT POSITION SENSOR
ELECTRONIC BRAKE CONTROL MODULE (ON LEFT SIDE OF FRAME ASSEMBLY)
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGNITION SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER DRIVER'S SEAT)
INSTRUMENT CLUSTER
INSTRUMENT PANEL JUNCTION BLOCK
IPC IGN/SDM IGN FUSE
KEY-IN IGNITION SWITCH
LEFT INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT
LO SPD GMLAN SERIAL DATA
LOGIC
LOW TIRE PRESSURE IND
LT GRN WIRE
LT GRN/GRY WIRE
NCA WIRE
OFF
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PASS SEAT BELT IND
PASSENGER AIR BAG DISABLE INDICATOR
PASSENGER SEAT BELT SWITCH PASSENGER SEAT BELT BUCKLE
PASSENGER SEAT POSITION SENSOR
RED/BLU WIRE
RED/GRY WIRE
RUN WIRE
RUN/CRANK
SEAT BELT IND
SEAT BELT ON IND
SIDE OF DASH)
VIO/BLK WIRE
VIO/WHT WIRE
WHT WIRE
WHT/VIO WIRE
Go to component -> Warning systems circuit (1 of 2) -> PASSENGER SEAT POSITION SENSOR
