Chevrolet Silverado GMT K2XX (2013-2015) pass mod sw sig pass mod sw retrn low spd gmlan serial data Wiring diagram
This page shows the only wiring diagram for the component.pass mod sw sig pass mod sw retrn low spd gmlan serial data, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass mod sw sig pass mod sw retrn low spd gmlan serial data (1 of 1)
AIR BAG IND
AIR BAG OFF IND
AIR BAG ON IND
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/YEL WIRE
GRY WIRE
GRY/ORG WIRE
HI SPD GMLAN
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER DRIVER'S SEAT)
INSTRUMENT CLUSTER
INSTRUMENT PANEL JUNCTION BLOCK
LO SPD GMLAN SERIAL DATA
LOGIC
LT GRN WIRE
ORG/ WIRE
ORG/LT GRN WIRE
ORG/VIO WIRE
ORG/WHT WIRE
PASS AIR BAG OFF IND
PASS MOD SW SIG PASS MOD SW RETRN LOW SPD GMLAN SERIAL DATA
PASS SEAT BELT IND PASS AIR BAG ON IND
PASSENGER AIR BAG DISABLE INDICATOR
PASSENGER INSTRUMENT PANEL AIR BAG
PNK WIRE
PPL
RED/LT GRN WIRE
ROLLOVER PROTECTION DISABLE SWITCH
SD COMM ENABLE
SD COMM ENABLE HI SPD GMLAN (+) GND
SEAT BELT IND
SEAT BELT ON IND
SHORTING BAR
STEERING WHEEL AIR BAG
STEERING WHEEL AIR BAG COIL
TAN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/DK BLU WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> PASS MOD SW SIG PASS MOD SW RETRN LOW SPD GMLAN SERIAL DATA
