Chevrolet Silverado GMT K2XX (2013-2015) low reference Wiring diagrams

This page contains all the electrical diagrams for the component. low reference, in which he is found in the car Chevrolet Silverado GMT K2XX (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram low reference (1 of 4)

Wiring diagram low reference for Chevrolet Silverado GMT K2XX (2013-2015) (1 of 4)

Get access

13 14 15 STOP LAMP SW SIG SENSOR LOW REF VOLT REFERENCE 6.0L (VIN G) AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR SIGNAL AUX HVAC- IGN FUSE 45 BATT GND BLK/WHT WIRE BRAKE PEDAL POSITION (BPP) SENSOR COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DASH) DK BLU WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY INSTRUMENT CLUSTER PANEL (IPC) ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD) EXCEPT 6.0L (VIN G) FUSE 19 GROUND DISTRIBUTION SYSTEM GRY WIRE HOT AT ALL TIMES HOT W/ RUN/CRNK RELAY ENERGIZED IGN LOGIC LOW REFERENCE LT GRN WIRE LT GRN/BLK WIRE ORG/BLK WIRE PC SOLENOID 1 CONTROL PC SOLENOID 2 CONTROL PC SOLENOID 3 CONTROL PC SOLENOID 4 CONTROL PC SOLENOID 5 CONTROL PNK IGN WIRE PNK WIRE PPL/WHT WIRE PRESSURE CONTROL (PC) SOLENOID VALVE 1 PRESSURE CONTROL (PC) SOLENOID VALVE 2 PRESSURE CONTROL (PC) SOLENOID VALVE 3 PRESSURE CONTROL (PC) SOLENOID VALVE 4 PRESSURE CONTROL (PC) SOLENOID VALVE 5 RED/WHT WIRE REPLICATED TOS SIGNAL SHIFT SOLENOID (SS) 1 CONTROL SHIFT SOLENOID (SS) 2 CONTROL SHIFT SOLENOID (SS) VALVE 1 SHIFT SOLENOID (SS) VALVE 2 TAN WIRE TAN/BLK WIRE TCM- BATT FUSE 14 TO AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) (DIAGRAM 2 OF 2) TORQUE CONVERTER CLUTCH (TCC) PRESSURE CONTROL (PC) SOLENOID VALVE TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL TOS SIG TOW/ HAUL IND TRANSMISSION CONTROL MODULE (TCM) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (ON TRANSFER CASE TAILSHAFT HOUSING) VSS HIGH SIG VSS LOW SIG

Go to component -> 6.0l vin b, a/t circuit (1 of 2) -> LOW REFERENCE

Wiring diagram low reference (2 of 4)

Wiring diagram low reference for Chevrolet Silverado GMT K2XX (2013-2015) (2 of 4)

Get access

Go to component -> 6.0l vin g, a/t circuit (1 of 2) -> LOW REFERENCE

Wiring diagram low reference (3 of 4)

Wiring diagram low reference for Chevrolet Silverado GMT K2XX (2013-2015) (3 of 4)

Get access

7 1 2 IGN DATA (-) DATA (+) AUTOMATIC TRANSMISSION ASSEMBLY AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR SIGNAL BATT GND BLK WIRE BLK/WHT WIRE BRN/WHT WIRE COMPT, NEAR FAN SHROUD) COMPUTER 5985 2500 2501 2139 2501 2500 DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY LOGIC INSTRUMENT CLUSTER ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE GRY/PPL WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED IGN IPC FUSE BLOCK FUSE (LOWER LEFT SIDE OF DASH) LOW REFERENCE PARK/NEUTRAL SIG GMLAN DATA BUS (-) GMLAN DATA BUS (+) PC SOLENOID 1 CONTROL PC SOLENOID 2 CONTROL PC SOLENOID 3 CONTROL PC SOLENOID 4 CONTROL PC SOLENOID 5 CONTROL POWER DISTRIBUTION SYSTEM PRESSURE CONTROL (PC) SOLENOID VALVE 1 PRESSURE CONTROL (PC) SOLENOID VALVE 2 PRESSURE CONTROL (PC) SOLENOID VALVE 3 PRESSURE CONTROL (PC) SOLENOID VALVE 4 PRESSURE CONTROL (PC) SOLENOID VALVE 5 RED/GRY WIRE RED/LT GRN WIRE REPLICATED TOS SIGNAL SHIFT SOLENOID (SS) 1 CONTROL SHIFT SOLENOID (SS) 2 CONTROL SHIFT SOLENOID (SS) VALVE 1 SHIFT SOLENOID (SS) VALVE 2 TCM/ECM FUSE TO TRANSMISSION INTERNAL MODE SWITCH (IMS) (DIAGRAM 2 OF 2) TORQUE CONVERTER CLUTCH (TCC) PRESSURE CONTROL (PC) SOLENOID VALVE TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL TOS SIG TOW/ HAUL IND TRANS IGN FUSE 40 TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VIO/BLK WIRE VIO/YEL WIRE WHT WIRE WHT/GRN WIRE WHT/GRY WIRE

Go to component -> A/t circuit (1 of 2) -> LOW REFERENCE

Wiring diagram low reference (4 of 4)

Wiring diagram low reference for Chevrolet Silverado GMT K2XX (2013-2015) (4 of 4)

Get access

4 6 BATT POS VOLT GND 6 4 GND BATT POS VOLT BACK IND BCK, CUSH BLK WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COOL IND DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DRIVER DOOR LOCK/ WINDOW SWITCH DRIVER MEMORY/ HEATED, COOLED SEAT SWITCH DRV HEAT COOL CTRL DRV HEAT COOL SW SIG DRV HEAT HI TEMP CTRL DRV HEAT LO TEMP CTRL DRV HEAT MID TEMP CTRL DRV SEAT BACK CTRL DRV ST BCK, CSH CTRL GMLAN SERIAL DATA GROUND DISTRIBUTION SYSTEM GRY WIRE HI IND HOT AT ALL TIMES I/P FUSE BLOCK LO IND LOW REFERENCE LT BLU WIRE LT GRN/BLK WIRE MEMORY SW DIM CTRL MID IND ORG/ WIRE PAS HEAT COOL CTRL PAS HEAT COOL SW SIG PAS HEAT HI TEMP CTRL PAS HEAT LO TEMP CTRL PAS HEAT MID TEMP CTRL PAS SEAT BACK CTRL PAS ST BCK, CSH CTRL PASSENGER DOOR LOCK/ WINDOW SWITCH PASSENGER HEATED, COOLED SEAT SWITCH PDM FUSE 9 PNK LOW REFERENCE WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL DRV SEAT BACK CTRL PPL PAS HEAT BACK CTRL RED WIRE RED/WHT WIRE RIGHT I/P JUNCTION BLOCK (IN RIGHT END OF DASH) SEAT BACK) SEAT COOL SEAT HEAT TAN WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Climate control seats circuit (2 of 2) -> LOW REFERENCE

Chevrolet Silverado GMT K2XX (2013-2015) low reference Wiring diagrams

Wiring diagram low reference (1 of 4)

List of components:

Wiring diagram low reference (2 of 4)

List of components:

Wiring diagram low reference (3 of 4)

List of components:

Wiring diagram low reference (4 of 4)

List of components:
