Chevrolet Silverado GMT K2XX (2013-2015) left instrument Wiring diagram
This page shows the only wiring diagram for the component.left instrument, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left instrument (1 of 1)
12 VOLT REF
24 25 HI SPD GMLAN SRL DATA (-) HI SPD GMLAN SRL DATA (+)
5360 5361 BRK APPLY SENS LO REF
7 13 STP LP SW SIG 5 VOLT SIG
ADAP CRUISE CTRL UP DWN SW SIG
BATT POS VOLT
BCM 1 PANEL FUSE FUSE BLOCK
BLK WIRE
BLK/BRN WIRE
BLK/DK BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR (BEHIND BRAKE PEDAL ASSEMBLY)
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CTRL SET/COAST/ RES/ACC SW SIG
CRUISE/ETC/TCC/BRAKE SIG
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
ECM IGN FUSE
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD)
GROUND
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL JUNCTION BLOCK
LEFT INSTRUMENT
LT GRN/WHT WIRE
RED/WHT WIRE
SENSOR LO REF
SIG GND
THRTL ACTR CTRL CLOSE THRTL ACTR CTRL OPEN
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VIO/GRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Cruise control circuit (1 of 2) -> LEFT INSTRUMENT
