Chevrolet Silverado GMT K2XX (2013-2015) instrument panel cluster Wiring diagram
This page shows the only wiring diagram for the component.instrument panel cluster, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument panel cluster (1 of 1)
BACKUP LAMPS CIRCUIT
BATTERY FUSE BLOCK (ENGINE COMPT, TOP RIGHT)
BCM 1 FUSE
BCM 3 FUSE
BCM 7 FUSE
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DATA
DRIVER INFORMATION CENTER DISPLAY
FUSE 4
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
IPC FUSE
LAMP
LEFT BACKUP LAMP
LEFT INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LEFT LOWER TAIL/STOP, TURN SIGNAL LAMP
LEFT REAR SIDE MARKER LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TURN IND
LEFT UPPER TAIL/STOP, TURN SIGNAL LAMP
LOGIC
LT GRN WIRE
MARKER LAMP
POSITIVE BATT
POWER DISTRIBUTION SYSTEM
REAR BODY JUNCTION BLOCK
RED/GRY WIRE
RED/LT GRN WIRE
RED/WHT WIRE
RIGHT BACKUP
RIGHT LOWER TAIL/STOP,
RIGHT REAR SIDE
RIGHT TAIL LAMP ASSEMBLY
RIGHT TURN IND
RIGHT UPPER TAIL/STOP, TURN SIGNAL LAMP
SER GMLAN LO SPD
SIDE OF DASH)
TURN SIGNAL LAMP
VIO/GRY WIRE
VIO/WHT WIRE
VOLT
YEL/BLU WIRE
Go to component -> Exterior lamps circuit (2 of 4) -> INSTRUMENT PANEL CLUSTER
