Chevrolet Silverado GMT K2XX (2013-2015) high speed bus terminating Wiring diagram
This page shows the only wiring diagram for the component.high speed bus terminating, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high speed bus terminating (1 of 1)
12 10 HI SPD GMLAN SER DATA (-) 1 HI SPD GMLAN SER DATA (+) 1
22 14 TRAILER BRAKE ENABLE SIGNAL ACC WAKEUP SER DATA
26 29 6 18 HI SPD GMLAN SER DATA (+) 1 HI SPD GMLAN SER DATA (-) 1
27 28 5 17 HI SPD GMLAN SER DATA (+) 1 HI SPD GMLAN SER DATA (-) 1
3 4 HI SPD GMLAN SER DATA (+) 1 HI SPD GMLAN SER DATA (-) 1
CHASSIS CONTROL MODULE
CONTROL SOLENOID VALVE ASSEMBLY AUTOMATIC TRANSMISSION ASSEMBLY
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/YEL WIRE
ELECTRONIC BRAKE CONTROL MODULE (ON LEFT SIDE OF FRAME ASSEMBLY)
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD)
FRONTVIEW CAMERA MODULE (BEHIND INSIDE REARVIEW MIRROR)
FUEL PUMP DRIVER CONTROL MODULE (MOUNTED TO BRACKET ABOVE SPARE TIRE)
HIGH SPEED BUS TERMINATING
LO SPD GMLAN SER DATA
LT GRN WIRE
RESISTOR
SER DATA COMM ENABLE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
TRAILER BRAKE ENABLE SIGNAL
TRAILER BRAKE POWER CONTROL MODULE (MOUNTED TO BRACKET ABOVE SPARE TIRE)
VIO/YEL WIRE
W/O EXTENDED FUEL ECONOMY W/ EXTENDED FUEL ECONOMY
WHT WIRE
WHT/DK BLU WIRE
YEL/BLK WIRE
Go to component -> Computer data lines circuit (5 of 5) -> HIGH SPEED BUS TERMINATING
