Chevrolet Silverado GMT K2XX (2013-2015) door dead lock relay Wiring diagrams
This page contains all the electrical diagrams for the component. door dead lock relay, in which he is found in the car Chevrolet Silverado GMT K2XX (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram door dead lock relay (1 of 2)
AJAR SW SIG
BLK WIRE
BLU/WHT WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CHILD SECURITY LOCK DISABLE RELAY
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DOOR DEAD LOCK RELAY
DRIVER DOOR LOCK SWITCH
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/WHT WIRE
INSTRUMENT PANEL JUNCTION BLOCK
LIN BUS 3
LIN BUS 4
LOGIC
LT GRN/GRY WIRE
PASSENGER DOOR LATCH ASSEMBLY (IN REAR OF PASSENGER FRONT DOOR)
PASSENGER WINDOW SWITCH
RF DR
RIGHT REAR DOOR LATCH ASSEMBLY (CREW CAB: REAR OF RIGHT REAR DOOR)
RIGHT REAR WINDOW SWITCH
RR DR -
VIO/YEL WIRE
WHT/BLU WIRE
YEL WIRE
YEL/LT GRN WIRE
Go to component -> Forced entry circuit (2 of 3) -> DOOR DEAD LOCK RELAY
