Chevrolet Silverado GMT K2XX (2013-2015) cushion, back ind Wiring diagram
This page shows the only wiring diagram for the component.cushion, back ind, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cushion, back ind (1 of 1)
13 14 15 16 17 PPL
BACK
BACK IND
BLK WIRE
BLU WIRE
BRN WIRE
CUSHION, BACK
CUSHION, BACK IND
DK BLU WIRE
DK GRN WIRE
DRIVER HEATED SEAT SWITCH
GRY WIRE
LT BLU WIRE
MID
NCA WIRE
PASSENGER CUSHION HEATED SEAT ELEMENT (IN PASSENGER'S SEAT CUSHION)
PASSENGER HEATED SEAT SWITCH
PNK LT DK WIRE
PNK LT WIRE
PNK WIRE
PPL
PPL/WHT WIRE
TAN WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Heated seats circuit, without memory (2 of 2) -> CUSHION, BACK IND
