Chevrolet Silverado GMT K2XX (2013-2015) computer data lines system 5991 5290 Wiring diagrams

This page contains all the electrical diagrams for the component. computer data lines system 5991 5290, in which he is found in the car Chevrolet Silverado GMT K2XX (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram computer data lines system 5991 5290 (1 of 3)

Wiring diagram computer data lines system 5991 5290 for Chevrolet Silverado GMT K2XX (2013-2015) (1 of 3)

Get access

5 VOLT REFERENCE LOW REF 5359 5361 (OR 6109) (OR 6111) A/C COMPRESSOR CLUTCH RLY CTRL 5 VOLT REFERENCE (2) APP SENS 2 SIG A/C REFRIGERANT PRESSURE SENS SIG A/T M/T ACCESSORY WAKEUP SERIAL DATA AIR CONDITIONING SYSTEM AMBIENT AIR TEMPERATURE SENS SIG 5 VOLT REFERENCE (1) APP SENS 1 SIG BLK/BRN WIRE BLK/DK BLU WIRE BLK/LT GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM 5991 5290 CRUISE/ETC/TCC BRAKE SIGNAL DATA OUT SIGNAL DK BLU BLK/ WIRE DK BLU WIRE DK BLU/BLK WIRE DK BLU/GRY WIRE DK BLU/VIO WIRE DK BLU/WHT WIRE DK BLU/YEL WIRE ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD) EVAP CANISTER VENT SOL CTRL FUSED SUPPLY (3) BRAKE APPLY SENSOR LOW REF EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID VALVE (UNDER REAR OF VEHICLE) FUEL LEVEL SENS SIG SENS LOW REF FUEL LEVEL SENSOR FUEL LINE PRESSURE SENSOR SIGNAL FUEL PUMP FUEL PUMP, LEVEL SENSOR ASSEMBLY (INSIDE FUEL TANK) FUEL TANK PRESSURE (FTP) SENSOR (ON FUEL PUMP, SENDER ASSEMBLY) GRN WIRE GRY WIRE GRY/BLK WIRE LOW REF LT GRN/WHT WIRE POWERTRAIN RELAY COIL CONTROL RELAY FUSED SPLY (1) PPL/LT GRN WIRE PRESSURE SENSOR SIGNAL RED/BRN WIRE RED/LT GRN WIRE RUN/CRANK IGNITION 1 VOLTAGE BATTERY POSITIVE VOLTAGE LOW REF STARTING/CHARGING SYSTEM VIO/DK BLU WIRE VIO/YEL WIRE WHT LT GRN/ WIRE WHT WIRE WHT/DK BLU WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> Wiring diagram engine performance 4.3l vin h (1 of 6) -> COMPUTER DATA LINES SYSTEM 5991 5290

Wiring diagram computer data lines system 5991 5290 (2 of 3)

Wiring diagram computer data lines system 5991 5290 for Chevrolet Silverado GMT K2XX (2013-2015) (2 of 3)

Get access

5 VOLT REFERENCE LOW REF A/C COMPRESSOR CLUTCH RLY CTRL 5 VOLT REFERENCE (2) APP SENS 2 SIG A/C REFRIGERANT PRESSURE SENS SIG ACCESSORY WAKEUP SERIAL DATA AIR CONDITIONING SYSTEM AMBIENT AIR TEMPERATURE SENS SIG 5 VOLT REFERENCE (1) APP SENS 1 SIG BLK/BRN WIRE BLK/DK BLU WIRE BLK/LT GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM 5991 5290 CRUISE/ETC/TCC BRAKE SIGNAL DATA OUT SIGNAL DK BLU BLK/ WIRE DK BLU WIRE DK BLU/BLK WIRE DK BLU/GRY WIRE DK BLU/VIO WIRE DK BLU/WHT WIRE ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD) EVAP CANISTER VENT SOL CTRL FUSED SUPPLY (3) BRAKE APPLY SENSOR LOW REF EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID VALVE (UNDER REAR OF VEHICLE) FUEL LEVEL SENS SIG SENS LOW REF FUEL LEVEL SENSOR FUEL LINE PRESSURE SENSOR SIGNAL FUEL PUMP FUEL PUMP, LEVEL SENSOR ASSEMBLY (INSIDE FUEL TANK) FUEL TANK PRESSURE (FTP) SENSOR (ON FUEL PUMP, SENDER ASSEMBLY) GRY WIRE GRY/BLK WIRE LOW REF LT GRN WIRE LT GRN/WHT WIRE POWERTRAIN RELAY COIL CONTROL RELAY FUSED SPLY (1) PPL/LT GRN WIRE PRESSURE SENSOR SIGNAL RED/BRN WIRE RED/LT GRN WIRE RUN/CRANK IGNITION 1 VOLTAGE BATTERY POSITIVE VOLTAGE LOW REF STARTING/CHARGING SYSTEM VIO/DK BLU WIRE VIO/YEL WIRE WHT LT GRN/ WIRE WHT WIRE WHT/DK BLU WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> Wiring diagram engine performance 5.3l vin c (1 of 6) -> COMPUTER DATA LINES SYSTEM 5991 5290
