Chevrolet Silverado GMT K2XX (2013-2015) battery fuse block Wiring diagram
This page shows the only wiring diagram for the component.battery fuse block, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery fuse block (1 of 1)
BATTERY
BATTERY CURRENT SENSOR (RIGHT REAR OF ENGINE COMPT)
BATTERY FUSE BLOCK
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BRN WIRE
CHARGE IND
CHARGE IND CTRL
COMPUTER DATA LINES SYSTEM
CURRENT SENS LOW REF
CURRENT SENS SIG CURRENT SENS
DK BLU WIRE
DK BLU/VIO WIRE
DRIVER INFORMATION CENTER DISPLAY
ECM IGN FUSE
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
FUSE
FUSE 4
GENERATOR
GENERATOR FIELD DUTY CYCLE SIG
GRY WIRE
GRY/VIO WIRE
HI SPD GMLAN SRL DATA (-) (1)
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
LOGIC
LT GRN WIRE
MDL/ BATT RVC FUSE
MOST SERIAL DATA (+)
NEAR FAN SHROUD)
PPL
PPL/LT GRN WIRE
RED WIRE
RED/YEL WIRE
RUN/CRANK IGN 1 VOLT
SPLY VOLT
UNDERHOOD FUSE BLOCK (ON POSITIVE BATTERY TERMINAL)
VIO WIRE
VIO/BLK WIRE
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Charging circuit -> BATTERY FUSE BLOCK
