Chevrolet Silverado GMT K2XX (2013-2015) 9 18 245 244 unlck sig lck sig Wiring diagram
This page shows the only wiring diagram for the component.9 18 245 244 unlck sig lck sig, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 9 18 245 244 unlck sig lck sig (1 of 1)
11 12 781 780 UNLCK SIG LCK SIG
2 3 4 GMLAN
3 10 B+ GMLAN
7 9 6 LCK CNTRL UNLCK CNTRL UNLCK CNTRL 194 5921
9 18 245 244 UNLCK SIG LCK SIG
ANT B+
BACK DOOR UNLCK DIODE DRIVER DOOR
BCM DIM FUSE 7 FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH)
BRN/WHT WIRE
COAX
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER DOOR LATCH ASSEMBLY (REAR OF DRIVER'S DOOR)
DRIVER INFORMATION CENTER (DIC) DISPLAY
DSM FUSE 25
FRONT REAR DOOR DOOR LCK LCK DIODE DIODE
GMLAN
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES I/P FUSE BLOCK (LEFT SIDE OF DASH)
I/P FUSE BLOCK (LEFT SIDE OF DASH,
INSTRUMENT PANEL CLUSTER (IPC)
INTERIOR LIGHTS
KEYLESS ENTRY ANTENNA
LCK 1 FUSE 21
LCK 2 FUSE 11
LEFT REAR DOOR LATCH ASSEMBLY (CREW CAB: REAR OF LEFT REAR DOOR)
LOCK ACTUATOR
LOCK PCB RELAY
LT BLU WIRE
ORG/BLK WIRE
PASSENGER DOOR LATCH ASSEMBLY (REAR OF PASSENGER'S FRONT DOOR)
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (TOP REAR OF PASSENGER COMPT)
RIGHT I/P JUNCTION BLOCK (IN RIGHT END OF DASH)
SECURITY INDICATOR LOGIC
SYSTEM
TAN WIRE
UNLCK 2 FUSE 10
UNLCK DIODE PDM FUSE 9 DRV UNLCK FUSE 26 UNLCK 1 FUSE 18
UNLOCK PCB RELAY
W/O POWER WINDOW
WHT WIRE
Go to component -> Power door locks circuit, with bucket seats & power mirrors -> 9 18 245 244 UNLCK SIG LCK SIG
