Chevrolet Silverado GMT K2XX (2013-2015) 2 3 5 6 pnk low ref low ref low ref low ref Wiring diagram
This page shows the only wiring diagram for the component.2 3 5 6 pnk low ref low ref low ref low ref, which is found in the car Chevrolet Silverado GMT K2XX (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2 3 5 6 pnk low ref low ref low ref low ref (1 of 1)
1 14 11 4 6 PPL PNK ELEM CTRL SPLY VOLT ELEM CTRL ELEM CTRL SPLY VOLT WIRE
1 4 5 6 GND GND B+ B+
2 3 5 6 PNK LOW REF LOW REF LOW REF LOW REF WIRE
4 1 3 2 TEMP SIG TEMP SIG TEMP SIG TEMP SIG
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER BACK HEATED SEAT ELEMENT (IN DRIVER'S SEAT BACK)
DRIVER CUSHION HEATED SEAT ELEMENT (IN DRIVER'S SEAT CUSHION)
DRIVER SEAT 2
GRY WIRE
HOT AT ALL TIMES
LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MEMORY SEAT MODULE (UNDER FRONT OF DRIVER'S SEAT)
NCA WIRE
PASSENGER BACK HEATED SEAT ELEMENT (IN PASSENGER'S SEAT BACK)
PASSENGER CUSHION HEATED SEAT ELEMENT (IN PASSENGER'S SEAT CUSHION)
PNK ELEM CTRL WIRE
PNK WIRE
PPL
RED/WHT WIRE
SERIAL DATA
TAN WIRE
TAN/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Heated seats circuit, with memory (1 of 2) -> 2 3 5 6 PNK LOW REF LOW REF LOW REF LOW REF WIRE
