Chevrolet Silverado Classic 3500 (2007-2007) left rear window switch Wiring diagram
This page shows the only wiring diagram for the component.left rear window switch, which is found in the car Chevrolet Silverado Classic 3500 (2007-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear window switch (1 of 1)
2 HI IND CONTROL
2-HI IND
4 HI IND CONTROL
4 LO IND CONTROL
4-HI IND
4-LO IND
AUTO
BATTERY (B+)
BLK WIRE
BRN/WHT WIRE
CREW CAB ONLY
DIMMING INPUT
DIMMING LO REF
DK GRN/WHT WIRE
DRL OFF
ELECTRONIC POWER STEERING SYSTEM
EXCEPT HYBRID
FOG LAMP RLY CTRL DRL OFF IND CTRL HEADLAMP ON IND CTRL 5 VOLT REF PPL PNK WIRE
FUSE
GRY WIRE
GRY/BLK WIRE
HEADLAMP ON
HEADLAMP SWITCH
HOT AT ALL TIMES
I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH)
IND
INST PANEL DIMMING LED DIMMING SUPPLY I/P LAMPS DIM SUPPLY
INSTRUMENT PANEL CLUSTER
LEFT REAR WINDOW SWITCH
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK AWD IND CONTROL WIRE
PNK WIRE
PPL
PPL/WHT WIRE
RED WIRE
RIGHT REAR WINDOW SWITCH
TAN/BLK WIRE
TRANSFER CASE SHIFT CONTROL MODULE (BEHIND HEADLAMP SWITCH)
TRANSFER CASE SHIFT CONTROL SWITCH
Go to component -> Instrument illumination circuit (1 of 3) -> LEFT REAR WINDOW SWITCH
