6.6l vin 2, charging circuit for Chevrolet Silverado 3500 (2002-2006)

AUXILIARY BATTERY RELAY (RIGHT REAR OF ENG COMPT) BATTERY BATTERY NOT CHARGING BLK WIRE BLK/WHT WIRE BRN WIRE CHARGE INDICATOR CONTROL CLASS 2 SERIAL DATA COMPUTER DATA LINES DK GRN WIRE DRIVER INFO CENTER ENGINE CONTROL MODULE (ECM) (ON LEFT FRONT OF ENGINE COMPARTMENT) FUSIBLE LINK 1 (8 GA- FUSIBLE LINK 2 (8 GA- FUSIBLE LINK 5 (5 GA- FUSIBLE LINK 6 (5 GA- GENERATOR 2 GENERATOR FIELD DUTY CYCLE SIGNAL GROUND GRY WIRE HOT IN RUN, START I/P RELAY BLOCK (NEAR LEFT KICK PANEL) IGN 1 VOLT IGN E FUSE INSTRUMENT PANEL CLUSTER LEFT BATTERY LEFT GENERATOR LOGIC MEGA FUSE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RIGHT BATTERY RIGHT BATTERY (W/AUX BATTERY) RIGHT GENERATOR SEO IGN FUSE SERIAL DATA CLASS 2 STARTER UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENG COMPT) VOLTS W/ SEO W/AUX BATTERY W/DUAL BATTERIES W/O SEO WRECKER OPTION
