Chevrolet Silverado 3500 (2002-2006) sensor signal sensor ground Wiring diagram
This page shows the only wiring diagram for the component.sensor signal sensor ground, which is found in the car Chevrolet Silverado 3500 (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sensor signal sensor ground (1 of 1)
AIR BAG FUSE
AIR BAG INDICATOR
BLK WIRE
BLK/WHT WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
FUSE BLOCK (ON LOWER LEFT SIDE OF DASH)
GROUND
GRY WIRE
HIGH CONTROL CLASS 2 SERIAL DATA
HIGH CONTROL LOW CONTROL LOW CONTROL INDICATOR CONTROL DISABLE SIGNAL PNK WIRE
HOT IN RUN, START
IGN 1 FUSE
IGNITION
INFLATABLE RESTRAINT I/P MODULE
INFLATABLE RESTRAINT I/P MODULE DISABLE SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER DRIVER'S SEAT)
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
JUNCTION BLOCK-BODY (UNDER LEFT SIDE OF DASH, NEAR LEFT KICK PANEL)
NCA WIRE
OFF ON
OFF PNK WIRE
PNK WIRE
PPL 1132
PPL/WHT WIRE
SENSOR SIGNAL SENSOR GROUND
SHORTING BAR
SOLID STATE
SPLICE PACK 205
TAN/BLK WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraint circuit -> SENSOR SIGNAL SENSOR GROUND
