Chevrolet Silverado 3500 (2002-2006) pwr maint relay Wiring diagrams
This page contains all the electrical diagrams for the component. pwr maint relay, in which he is found in the car Chevrolet Silverado 3500 (2002-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pwr maint relay (1 of 2)
AUX HTR PUMP FUSE
AUX HTR PUMP RELAY
AUXILIARY WATER PUMP
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
COOL PUMP FUSE
COOL/ FAN RELAY 1
COOL/ FAN RELAY 2
COOL/ FAN RELAY 3
COOL/FAN FUSE
DK (IN FORWARD LAMP HARNESS)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HYBRID CONTROL MODULE (HCM)
IGN B FUSE
LEFT COOLING FAN
ORG/ WIRE
PNK PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM)
PPL
PWR MAINT FUSE
PWR MAINT RELAY
RED WIRE
RIGHT COOLING FAN
SECONDARY UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) (HYBRID)
SGCM COOL PMP/FAN RELAY
STARTER GENERATOR CONTROL MODULE (SGCM)
STARTER/GENERATOR CONTROL MODULE COOLANT PUMP
STUD 1 FUSE
TAN WIRE
UNDERHOOD COOLING FAN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> PWR MAINT RELAY
Wiring diagram pwr maint relay (2 of 2)
AUX HTR PUMP FUSE
AUX HTR PUMP RELAY
AUXILIARY WATER PUMP
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
COOL PUMP FUSE
COOL/ FAN RELAY 1
COOL/ FAN RELAY 2
COOL/ FAN RELAY 3
COOL/FAN FUSE
DK (IN FORWARD LAMP HARNESS)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HYBRID CONTROL MODULE (HCM)
IGN B FUSE
LEFT COOLING FAN
ORG/ WIRE
PNK PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM)
PPL
PWR MAINT FUSE
PWR MAINT RELAY
RED WIRE
RIGHT COOLING FAN
SECONDARY UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) (HYBRID)
SGCM COOL PMP/FAN RELAY
STARTER/GENERATOR CONTROL MODULE (SGCM)
STARTER/GENERATOR CONTROL MODULE COOLANT PUMP
STUD 1 FUSE
TAN WIRE
UNDERHOOD COOLING FAN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit (3 of 3) -> PWR MAINT RELAY
