6.6l vin 8, cooling fan circuit for Chevrolet Silverado 3500 HD (2007-2012)

2500 2501 COMPUTER DATA LINES SYSTEM 66 46 SERIAL DATA + SERIAL DATA - BLK WIRE BLK/WHT WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY ECT SENS SIG ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD) ENGINE COOLANT LEVEL SWITCH (ON BOTTOM OF SURGE TANK) ENGINE COOLANT TEMPERATURE (ECT) SENSOR (TOP FRONT CENTER OF ENGINE) ENGINE COOLING FAN (FRONT CENTER OF ENGINE COMPT) FAN FUSE 68 FAN RLY RELAY GRY WIRE HOT AT ALL TIMES HVAC CONTROL MODULE INSTRUMENT PANEL CLUSTER (IPC) LOGIC LOGIC B+ GND LOW REF LT GRN WIRE MANUAL A/C AUTOMATIC A/C RLY SPD SIG SERIAL DATA SPD SIG SW SIG TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE
