Anti-lock brakes circuit, except hybrid greater than/equal to 8600 gvw with active brake control for Chevrolet Silverado 3500 HD (2007-2012)

12 VOLT REF 12-VOLT REF ANGLE SENSOR PHASE B CAN BUS LOW SERIAL DATA 12-VOLT REF LF WHEEL SPD SENS SIG 16 17 2500 2501 COMPUTER DATA BUS + DATA BUS - DATA LINES SYSTEM 2501 2501 COMPUTER DATA LINES SYSTEM 3 5 SENS PHASE A SENS PHASE C 5-VOLT REF VEHICLE SPEED SIGNAL CAN BUS HIGH SERIAL DATA ABS INDICATOR ABS-1 FUSE 61 (GAS) FUSE 56 (DIESEL) BLK WIRE BLK/ WHT WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER RESERVOIR) BRAKE PRESSURE MODULATOR VALVE BRAKE WARNING INDICATOR BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (ON LEFT SIDE OF FRAME ASSEMBLY) EXCEPT LUXURY GAS GROUND GRY WIRE GRY/BLK WIRE GRY/WHT WIRE HI SERIAL DATA HOT AT ALL TIMES I/P MULTI-FUNCTION SWITCH INSTRUMENT PANEL CLUSTER (IPC) IPC FUSE LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH) LEFT REAR WHEEL SPEED SENSOR (WSS) (ON LEFT REAR BRAKE BACKING PLATE) LO SERIAL DATA LOGIC LOW REF 12-VOLT REF LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LUXURY NCA WIRE ORG/BLK WIRE ORG/WHT WIRE PARK BRAKE SW SIG PARK BRAKE SWITCH (ON PARK BRAKE PEDAL ASSEMBLY) POWER DISTRIBUTION SYSTEM PPL PPL BRAKE SW SIG RED/BLK WIRE RED/WHT WIRE RIGHT REAR WHEEL SPEED SENSOR (WSS) (ON RIGHT REAR BRAKE BACKING PLATE) SENS PHASE B SERIAL DATA SERIAL DATA BATTERY POSITIVE VOLTAGE SERIAL DATA BUS (+) SERIAL DATA BUS (+) BATTERY POSITIVE VOLTAGE SERIAL DATA BUS- SERIAL DATA BUS- GROUND SIG TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TRACTION CONTROL SWITCH SIGNAL TRACTION CTRL SW SIG VEHICLE SPD SIG RADIO YAW RATE, LATERAL ACCELERATION SENSOR (UNDER CENTER CONSOLE TRIM PANEL) YEL WIRE YEL/BLK WIRE
