Chevrolet Silverado 2500 (2000-2004) unlock ctrl lock ctrl relay ctrl battery serial data Wiring diagram
This page shows the only wiring diagram for the component.unlock ctrl lock ctrl relay ctrl battery serial data, which is found in the car Chevrolet Silverado 2500 (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram unlock ctrl lock ctrl relay ctrl battery serial data (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH, NEAR STEERING COLUMN)
DK BLU WIRE
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR LOCK SWITCH
DRIVER UNLOCK RELAY
FRONT PASSENGER DOOR LOCK ACTUATOR
FRONT PASSENGER DOOR LOCK SWITCH
GASOLINE DIESEL
GRY WIRE
HOT AT ALL TIMES
I/P RELAY BLOCK (NEAR LEFT KICK PANEL)
IGNITION KEY ALARM SWITCH (ON IGNITION KEY CYLINDER)
INSTRUMENT PANEL CLUSTER
LEFT I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH)
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LOCK RELAY
LOCKS FUSE
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PCM ECM (LEFT FRONT OF ENGINE COMPARTMENT)
RIGHT I/P FUSE BLOCK (LOWER RIGHT SIDE OF DASH)
RIGHT REAR DOOR LOCK ACTUATOR
SERIAL DATA
SPLICE PACK
TAN WIRE
UNLOCK
UNLOCK CTRL LOCK CTRL IGN KEY SW
UNLOCK CTRL LOCK CTRL RELAY CTRL BATTERY SERIAL DATA
UNLOCK RELAY
W/ CREW CAB
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit, base -> UNLOCK CTRL LOCK CTRL RELAY CTRL BATTERY SERIAL DATA
