Chevrolet Silverado 2500 (2000-2004) front overhead reading lamps Wiring diagram
This page shows the only wiring diagram for the component.front overhead reading lamps, which is found in the car Chevrolet Silverado 2500 (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front overhead reading lamps (1 of 1)
AMPLIFIER
AUTOMATIC DAY-NIGHT REARVIEW MIRROR W/ COMPASS
AUXILIARY POWER OUTLET AUXILIARY POWER OUTLET
BLK WIRE
BLOWER MOTOR SWITCH/HVAC CONTROL MODULE
BODY CONTROL MODULE
BODY WIRING HARNESS JUNCTION BLOCK (UNDER LEFT SIDE OF DASH)
BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID
CENTER HIGH MOUNTED STOP/ CARGO LAMP
CIGAR LIGHTER ASHTRAY LAMP
COURTESY LAMP RELAY
DATA LINK CONNECTOR (DLC)
FOG/ CARGO LAMP SWITCH
FRONT OVERHEAD READING LAMPS
FUSE BLOCK (LOWER LEFT SIDE OF DASH) POWER DOOR LOCKS RELAY TURN/ HAZARD FLASHER
HEADLAMP, PANEL DIMMER SWITCH
HEATED/ MEMORY SEAT SWITCH
HORN SWITCH
INSTRUMENT CLUSTER
KEY CYLINDER SWITCH TOW/HAUL SWITCH
LEFT MINI WEDGE (DOOR JAMB SWITCH)
LEFT OUTSIDE POWER MIRROR POWER MIRROR SWITCH LEFT DOOR KEY SWITCH
LEFT POWER WINDOW/ DOOR LOCK SWITCH
MODE DOOR MOTOR SELECT SWITCH
NCA WIRE
PARK SWITCH
POWER DOOR LOCK SWITCH
POWER WINDOW SWITCH
RADIO
RECIRCULATION DOOR MOTOR
REMOTE CONTROL DOOR LOCK RECEIVER
RIGHT MINI WEDGE (DOOR JAMB SWITCH)
RIGHT POWER DOOR LOCK SWITCH
ROOF BEACON SWITCH
SELECTABLE RIDE SWITCH
STEERING COLUMN)
SWITCH
TEMPERATURE DOOR MOTOR
TRACTION ASSIST
UPLEVEL ONLY (UPLEVEL ONLY)
VEHICLE INTERFACE UNIT (VIU)
Go to component -> Ground distribution circuit (2 of 3) -> FRONT OVERHEAD READING LAMPS
