Warning systems circuit, with an3/dl3 for Chevrolet Silverado 2500 HD (2002-2012)

1 2 3 4 9 10 BATTERY (+) BATTERY (+) BATTERY (+) BATTERY (+) GROUND BATTERY (+) 14 15 RIGHT REAR DOOR AJAR SW LEFT REAR DOOR AJAR SW 5 4 13 9 LOW REF LF OPEN SIG LF AJAR SIG LO SPD DATA 9 5 13 LO SPD DATA LOW REF RF AJAR SIG BCM FUSE BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CREW CAB CTSY FUSE DIM FUSE DK GRN WIRE DOOR) PNK WIRE DRIVER DOOR LATCH ASSEMBLY (IN REAR OF DRIVER FRONT DRIVER DOOR LOCK/ WINDOW SWITCH FRONT DOOR) GRY/BLK WIRE HEAD HEAD OFF AUTO PARK HEADLAMP, PANEL DIMMER SWITCH HOT AT ALL TIMES I/P FUSE BLOCK (LEFT SIDE IS LPS FUSE LEFT REAR DOOR LATCH ASSEMBLY (REAR OF LEFT REAR DOOR) LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT STOP TRN FUSE OF DASH) OFF AUTO PARK PARK BRAKE SW SIGNAL PASSENGER DOOR LATCH ASSEMBLY (IN REAR OF PASSENGER PASSENGER DOOR LOCK/ WINDOW SWITCH PNK IGN III WIRE POWER DISTRIBUTION SYSTEM RED/WHT WIRE RIGHT I/P JUNCTION BLOCK (IN RIGHT END OF DASH) RIGHT REAR DOOR LATCH ASSEMBLY (REAR OF RIGHT REAR DOOR) RT STOP TRN FUSE STOP LAMPS FUSE TAN WIRE TAN/BLK WIRE TAN/WHT WIRE WHT WIRE YEL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 B+ 1 8 13 B+ LOW REF LO SPD DATA BLK WIRE BLK/WHT WIRE BLU WIRE BRAKE IND CHIME MODULE (CENTER OF DASH, BEHIND RADIO) DK GRN WIRE DLIS FUSE 35 FUSE 32 DRIVER SEAT BELT BUCKLE DRIVER SEAT BELT SW SIG DRIVER SEAT BELT SWITCH GAS DIESEL HOT AT ALL TIMES IGNITION SWITCH INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER DRIVER'S SEAT) INSTRUMENT PANEL CLUSTER (IPC) IPC FUSE 46 FUSE 43 KEY-IN IGNITION SWITCH LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH) LO SPD GMLAN SERIAL DATA LOGIC LOW REF LOW TIRE PRESSURE IND LT BLU WIRE NCA WIRE PARK BRAKE SWITCH (ON PARK BRAKE PEDAL ASSEMBLY) PNK LOW REF WIRE PNK PNK SUPPLEMENTAL RESTRAINTS SYSTEM WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL RADIO RDO FUSE 42 FUSE 39 RED/WHT WIRE SEAT BELT IND SERIAL DATA SOUND SYSTEMS SPLICE PACK TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) W/ LUXURY EDITION W/ RADIO PROVISIONS W/O RADIO PROVISIONS WHT WIRE
