Manual a/c circuit, front a/c for Chevrolet Silverado 2500 HD (2002-2012)

80 13 45 21 14 33 43 41 58 15 (GASOLINE) (DIESEL) A/C COMP CL RLY CTRL A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C LOW PRESSURE SWITCH (RIGHT SIDE OF ACCUMULATOR) A/C ON SWITCH A/C RECIRC A/C REF PRE SENS SIG A/C REFRIGERANT PRESSURE SENSOR (IN HIGH SIDE PRESSURE LINE) BLK WIRE BLK/WHT WIRE BLOWER FUSE BLOWER MOTOR (UNDER RIGHT SIDE OF DASH) BLOWER MOTOR CONTROL SWITCH BLOWER MOTOR RELAY BLOWER MOTOR RESISTOR ASSEMBLY (ON HVAC MODULE, NEAR BLOWER MOTOR) BRN WIRE BRN/WHT WIRE CLASS 2 SER DATA CLASS 2 SERIAL DATA DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE FRT DEF GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES A/C COMP FUSE HOT IN HOT IN RUN OR START IGN E FUSE HTR A/C FUSE HVAC 1 FUSE HVAC CONTROL MODULE (BEHIND CENTER OF DASH) HVAC/ ECAS FUSE I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH) I/P JUNCTION BLOCK (LOWER RIGHT SIDE OF DASH) I/P RELAY BLOCK (LEFT SIDE OF DASH) INST LAMP DIM CTRL GROUND LEFT TEMP CONTROL LOGIC LOW REF LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE MODE CONTROL MODE DOOR CTRL MODE DOOR CTRL IGN 3 LOW REF B(+) OFF OFF BLOW MT CTRL LO PRESS SENS SIG RT TEMP DOOR CTRL LT TEMP DOOR CTRL ORG/ WIRE POWERTRAIN CONTROL MODULE OR ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) PPL RECIR DOOR CTRL RT TEMP DOOR CTRL LT TEMP DOOR CTRL RECIRC SWITCH RED WIRE RED/BLK WIRE RIGHT TEMP CONTROL RUN WIRE TAN WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEAR BATTERY) WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN) BRN WIRE CLASS 2 SERIAL DATA DK BLU WIRE DK GRN WIRE I/P JUNCTION BLOCK (LOWER RIGHT SIDE OF DASH) LEFT AIR TEMPERATURE ACTUATOR (BOTTOM OF HVAC MODULE) LOGIC LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE MODE ACTUATOR (LEFT SIDE OF HVAC MODULE) RECIRCULATION ACTUATOR (UPPER RIGHT OF HVAC MODULE) LOGIC RIGHT AIR TEMPERATURE ACTUATOR (TOP OF HVAC MODULE) TAN WIRE WHT/BLK WIRE YEL WIRE
