Chevrolet Silverado 2500 HD (2002-2012) sliding rear window open relay Wiring diagram
This page shows the only wiring diagram for the component.sliding rear window open relay, which is found in the car Chevrolet Silverado 2500 HD (2002-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sliding rear window open relay (1 of 1)
ACCES- SORY VOLTAGE
BLK WIRE
BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH)
BRN/WHT WIRE
CLOSE
HOT AT ALL TIMES
ILLUMI- NATION
LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH)
POWER DISTRIBUTION SYSTEM
PPL
PWR REAR WNDW CIRCUIT BREAKER
RED WIRE
RED/WHT WIRE
SLIDING REAR WINDOW CLOSE RELAY
SLIDING REAR WINDOW MOTOR (RIGHT REAR OF PASSENGER COMPT)
SLIDING REAR WINDOW OPEN RELAY
SLIDING REAR WINDOW SWITCH
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Sliding rear window circuit -> SLIDING REAR WINDOW OPEN RELAY
