Chevrolet Silverado 2500 HD (2002-2012) outside ign moisture volt sensor signal Wiring diagram
This page shows the only wiring diagram for the component.outside ign moisture volt sensor signal, which is found in the car Chevrolet Silverado 2500 HD (2002-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside ign moisture volt sensor signal (1 of 1)
12 VOLT REFERENCE
BAT POS VOLT
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
GROUND
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT SIDE OF DASH,
LT GRN WIRE
OUTSIDE IGN MOISTURE VOLT SENSOR SIGNAL
OUTSIDE MOISTURE SENSOR SIGNAL
OUTSIDE MOISTURE SIG 1
OUTSIDE MOISTURE SIG 2
POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
RIGHT I/P JUNCTION BLOCK (IN RIGHT END OF DASH)
RT STOP TRN FUSE 8
SERIAL DAT
TAN WIRE
WHT WIRE
WINDSHIELD OUTSIDE MOISTURE SENSOR (NEAR INSIDE REARVIEW MIRROR MOUNT)
