Chevrolet Silverado 2500 HD (2002-2012) hot in run or start pcm 1/afs fuse Wiring diagram
This page shows the only wiring diagram for the component.hot in run or start pcm 1/afs fuse, which is found in the car Chevrolet Silverado 2500 HD (2002-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in run or start pcm 1/afs fuse (1 of 1)
AF INJECTOR
BATTERY
BLK LT BLU/ WIRE
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/ WHT WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
ENABLE
EVEN
FUEL INJECTOR CONTROL MODULE (FICM) (BELOW AIR FILTER ASSEMBLY)
FUSIBLE LINK
GRY WIRE
HOT IN RUN OR START PCM 1/AFS FUSE
IGN
INJ 1
INJ 2
INJ 3
INJ 4
INJ 5
INJ 6
INJ 7
INJ 8
INLINE AF FUSE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/ BLK WIRE
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
OUT
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL PNK PNK WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
REF
SIG
STATUS
TAN WIRE
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 6.0l bi-fuel (4 of 8) -> HOT IN RUN OR START PCM 1/AFS FUSE
