6.0l vin n, charging circuit for Chevrolet Silverado 1500 (2000-2012)

AUXILIARY BATTERY RELAY (RIGHT REAR OF ENG COMPT) BATTERY BLK WIRE BLK/WHT WIRE BRN WIRE CHARGE INDICATOR CONTROL COMPUTER DATA LINES DK BLU WIRE DK GRN WIRE EXC 4.3L, 8.1L 4.3L, 8.1L FUSE HOLDER FUSIBLE LINK GENERATOR GENERATOR FIELD DUTY CYCLE SIGNAL GROUND GRY WIRE HOT IN RUN, START I/P RELAY BLOCK (NEAR LEFT KICK PANEL) IGN 1 VOLT IGN E FUSE INSTRUMENT PANEL CLUSTER IPC CLASS 2 SERIAL DATA LEFT BATTERY LOGIG PNK WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) (ON LEFT FRONT OF ENGINE COMPARTMENT) RED WIRE RIGHT BATTERY RIGHT BATTERY (W/AUX BATTERY) SEO IGN FUSE SERIAL DATA CLASS 2 STARTER SUPPLEMENTAL BRAKE ASSIST (SBA) PUMP MOTOR (MOUNTED TO POWER BRAKE BOOSTER) UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENG COMPT) UPFITTER OPTION VOLTS W/ SEO W/AUX BATTERY W/DUAL BATTERIES W/O SEO
